Description of the device

4 Description of the device
The Servitec Mini is a water degassing system for use in small systems of up to 1 m
4.1

Overview

1 Venting grille
2 Hinge for folding up
3 Controller
4 Gas-rich water inlet
5 Dirt trap
6 Degassed water outlet
7 Folds up in the direction of the arrow
4.2

Identification

The nameplate provides information on manufacturer, year of manufacture, part number and
technical data. The nameplate is located on the rear side of the controller inside the system.
Information on the type plate
Type
Serial No.
min. / max. allowable pressure P
min. / max. continuous operating temperature
Year built
8 — English
Meaning
Device name
Serial number
Minimum/maximum permissible pressure
Minimum/maximum continuous operation
temperature
Year of manufacture
Servitec Mini — 10.10.2022-Rev. C
3 system volume.
