O P E R A T I N G I N S T R U C T I O N S
DL100 Pro CANopen
Distance sensor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL100 Pro CANopen and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SICK DL100 Pro CANopen

Summary of Contents for SICK DL100 Pro CANopen

  • Page 1 O P E R A T I N G I N S T R U C T I O N S DL100 Pro CANopen Distance sensor...
  • Page 2 This document is an original document of SICK AG.           O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Aligning the distance sensor and reflector with each other....Received signal level................Electrical installation................ 30 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 4 CiA 406 device profile............. 10.3.3 Object directory................ 10.3.4 EDS file..................O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 5 13.4 Inputs......................100 13.5 Outputs...................... 100 13.6 Interfaces....................100 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 6 15.1 Menu structure..................105 15.2 Declarations of conformity and certificates..........108 O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 7: About This Document

    … highlights useful tips and recommendations as well as information for efficient and trouble-free operation. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 8: Scope Of Delivery

    • Other publications • Software • Accessories O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 9: Safety Information

    Incorrect use ■ Use of untrained staff ■ 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 10: Modifications And Conversions

    O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 11: Warning Signs On The Device

    A class 2 laser is installed in the device. The housing is labeled with a warning sign. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 12: Ul Conformity

    {S/N} corresponds to the serial number of the product, see type label (if indicated). O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 13: Function And Use

    8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 14: Type Label

    The status of the device and the status of all interfaces is displayed by LEDs in accordance with the following table. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 15: Display

    "!" when the value -99,999 is undercut. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 16: Operating Pushbuttons

    Jump back to the next highest menu level or to the measured value display. ■ O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 17: Transport And Storage

    8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 18: Mounting

    The reflector must always be at least 100 mm x 100 mm in size, even if the light spot is smaller due to a shorter measuring distance. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...
  • Page 19 7, page 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 20 Tilt of approx. 1° to 3° Shiny surface suchas a rail O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 21: Placement Of Multiple Distance Sensors

    . This applies to mounting with light beams in both the same and opposite directions. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 22 Distance sensor Reflector Minimum distance Maximum travel distance O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 23: Arranging The Distance Sensor To The Adjacent Optical Data Transmission System

    Maximum travel distance Formula: a ≥ 0.0083 x s 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 24: Assignment To Isd300, Isd400-1Xxx Or Isd400-6Xxx

    The maximum measurement distance and variant of the distance sensor does not have an impact on the minimum distance. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 25: Mounting The Alignment Bracket And Distance Sensor

    Mount the alignment bracket using the four slotted holes with the supplied screws. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 26 Secure the star grip screw in place using a knurled nut. Knurled nut O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 27: Aligning The Distance Sensor And Reflector With Each Other

    M5 hex socket adjustment screw for aligning the distance sensor in the Y-direction 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 28: Received Signal Level

    Figure 15: Signal attenuation depends on the distance between device and reflector Typical signal attenuation O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...
  • Page 29 Signal damping in dB Distance in m 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 30: Electrical Installation

    Take appropriate measures to prevent equipotential bonding currents flowing ■ through the cable shield. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 31 Figure 17: Ideal laying – Place cables in different cable channels 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 32: Connecting The Device Electrically

    CANopen output (female connector M12, 5-pin, A-coded) CANopen input (male connector M12, 5-pin, A-coded) O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 33: Connection Diagrams

    CANopen input connection diagram (shield) V– CAN_H CAN_L 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 34 CAN bus signal Thread Shielding Cable lug (housing) O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 35: Operation

    Temperature Display of the internal device temperature 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 36: Swvers Menu

    CANopen menu Use this menu to parameterize the CANopeninterface O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 37: More? Menu

    In the more? menu, you can activate or deactivate the advanced menu view. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 38: Mfx On Menu

    Factory setting • ActLow O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 39: Mf1 - Dist Submenu

    Menu MFx On: Enable option ■ Functn parameter: Dist option ■ 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 40: Mf1 - Speed Submenu

    Menu MFx On: Enable option • Functn parameter: Speed option O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 41: Mf1 - Srvice Submenu

    Menu MFx On: Enable option • Functn parameter: Srvice option 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 42: Mf1 - Lsroff Submenu

    LsrOff. If MF1 is active, the laser diode is switched off. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 43: Mf1 - Preset Submenu

    You can parameterize MF2 in this menu and its submenus. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 44: Offset Menu

    –600,000 … +300,000 [mm] Factory setting • 0 [mm] O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 45: Specfu Menu

    • - (negative direction) Factory setting • 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 46: Performing A Reset

    Press the pushbutton to terminate the process. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 47 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 48: Ethernet Interface

    It may be necessary to reset to factory settings and restart the device. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 49: Sopas Et Configuration Software

    User information windows or a firmware update) . 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 50: Firmware Update

    ✓ Successful transmission of the new firmware is displayed. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 51 Update device driver via upload from the device. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 52 Firmware update and update of the device in the SOPAS project are complete. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 53: Canopen Interface

    EDS. The EDS also be used as an exchange format between software tools. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 54: General Canopen Installation Notes

    The device supports the CiA 301 communication profile in version 4.2. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 55: Cia 406 Device Profile

    DLC: Data Length Code 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 56: Structure Of 11-Bit Can Id

    The lower the CAN ID, the higher the priority of the telegram. The following figure shows the distribution and priority of the CAN identifiers. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 57: Communication Objects

    RTR allowed in this PDO No RTR allowed in this PDO 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 58: Canopen Services And Can Ids

    1920 – 2019 780h – 7E3h Not implemented O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 59: Nmt Network Management

    600h + node ID: CANopen Controller → CANopen Device (receive SDO) 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 60 Example: Index 1000h is represented as 00h | 10h. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 61: Synchronous And Asynchronous Pdos

    Synchronous (cyclic – every 3rd SYNC request) 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 62: Dl100 Pro Canopen Communication

    1001h – Error Regis‐ (All errors ter", page 70 set) O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 63 1017h Producer Time 65535d Heartbeat Time", page 72 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 64 NODE ID Transmission type Unsigned8 – – O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 65 Mapping Entry 1 Unsigned32 rw  429496729 161087491 FFFFFFFFh 60040020h 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 66 Mapping Entry 8 Unsigned32 rw 429496729 FFFFFFFFh O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 67 Unsigned8 4000h – Distance Resolution", page 77 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 68 1d, 1h 10000d, 100d, 64h Step 2710h O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 69 –600000 300000 6509h Offset Value", page 82 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 70: Communication Segment (1000H To 1Fffh)

    Number of Entries Number of stored errors. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 71 Specification of the COB ID of the EMCY object. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 72 Consecutive, unique number within the vendor ID, which is issued by the manufacturer. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...
  • Page 73 Communication parameter for asynchronous transmission of object 6004h, subindex 0h (position) 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 74 PDO. Compatibility Entry No function. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 75 Specification of the number of subindices within the object 1A01h. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 76: Manufacturer-Specific Segment (2000H To 5Fffh)

    Temperature warning 4...7 Reserve (reserve bit = 0) O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 77 Indication of the software version of the communication con‐ troller troller. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 78: Device Profile Cia 406 Absolute Linear Encoder

    Md (Measuring direction): The md bit defines the counting direction and inverts the current measured value. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...
  • Page 79 As an alternative to object 6003h, a preset can be made via switching input MF1, "MF1 – Preset submenu", page 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 80 Number of Available Specification of available channels Channels O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 81 1. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 82 Values Manufacturer Offset Manufacturer-specific offset value. For DL100 Pro this is 0. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 83: Tpdo Behavior At Distance Value

    CAN IDs. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 84 Another possibility is to map a manufacturer-specific TPDO, for example TPDO5, to the still free CAN ID range of TPDO1 (180h + node ID). O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 85: Emergency Messages (Emcy Messages)

    CiA40x device profiles). 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 86 EEC: Protocol error, PDO length exceeded O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...
  • Page 87 As long as no new warning and no new error occur, no further EMCY message will be sent. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 88: Commissioning In The Canopen Network

    A dialog window opens in the main window. Enter the node ID under the CANopen configuration grouping. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 89: Baud Rate Setting

    You can set the baud rate of the device via the display, SOPAS ET or via CANopen LSS (Layer Setting Service). 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 90 CAN‐ Device open device. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 91: Configuration Of Process Data Objects (Tpdos)

    Select the required TPDO1 (1800h) or TPDO2 (1801h) in the configuration tool. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 92 SOPAS ET configuration software. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 93: Maintenance

    Recommended: At least every 6 months. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 94: Troubleshooting

    Troubleshooting main menu (meaning) NoWrn No warning O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 95: Error Messages

    (meaning) NoErr No errors – 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 96: Communication Problems

    CiA 303-3 version 1.4.0, in which further detailed information about the timing and the red/green conflict behavior is found. O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 97: Returns

    The device must be sent in the original packaging or an equivalent padded pack‐ aging. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 98: Repairs

    Separate the recyclable materials by type and place them in recycling containers. ■ O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...

  • Page 99: Technical Data

    Statistical error 1 σ, environmental conditions constant, minimum warm-up time 10 min. 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 100: Supply

    –40 ... +55 °C (with integrated heating)  -20 ... +75 °C (with cooler housing TPCC) O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 101: Structural Design

    6-digit with a 5 x 7 dot matrix ■ 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 102: Dimensional Drawing

    Latch hook for alignment bracket Electrical connection Display and control elements O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 103: Accessories

    Part number 2058653 Material Galvanized sheet steel 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 104: Cooler Housing

    Enclosure rating IP55 (horizontal mounting) IP54 (vertical mounting) O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK Subject to change without notice...

  • Page 105: Annex

    Software and hardware versions Interface Multifunctional input/multifunctional outputs Indication only 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 106 The menu displayed depends on the selected function (Functn) see D ß O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...
  • Page 107 à For the variants DL100-xxHxxxxx only á 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...

  • Page 108: Declarations Of Conformity And Certificates

    {S/N} corresponds to the serial number of the product, see type label (if indicated). O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen 8015418/19HA/2022-12-15 | SICK...
  • Page 109 ANNEX 8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen Subject to change without notice...
  • Page 110 Phone +7 495 283 09 90 E-Mail info@sick.com E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com SICK AG  |  Waldkirch  |  Germany  |  www.sick.com...
