O P E R A T I N G I N S T R U C T I O N S
DT1000 PROFIBUS DP and
DL1000 PROFIBUS DP
Distance sensor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT1000 PROFIBUS DP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SICK DT1000 PROFIBUS DP

Summary of Contents for SICK DT1000 PROFIBUS DP

  • Page 1 O P E R A T I N G I N S T R U C T I O N S DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Distance sensor...
  • Page 2 This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 3: Table Of Contents

    Mounting the alignment bracket and distance sensor......8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 4 8.2.7 Configuring delay time for "No echo"........O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...
  • Page 5 Defining SSI coding..............8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 6 11.5 Classifications................... 115 11.6 Dimensional drawings................116 O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...
  • Page 7 13.2 Licenses....................120 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 8: About This Document

    … highlights useful tips and recommendations as well as information for efficient and trouble-free operation. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 9: Further Information

    Publications dealing with accessories 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 10: Safety Information

    O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 11: Modifications And Conversions

    8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 12: Laser Radiation

    Alignment laser (visible to the human eye) ■ O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 13: Hot Surface

    Figure 2: Warning sign on the device: HOT SURFACE 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 14: Product Description

    PROFIBUS DP interface, the SOPAS ET user interface (PC, via Ethernet) or via the Ethernet interface. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 15: Design

    The following information can be read off the device from the type label: 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 16: Switching Functions

    Hysteresis Hysteresis O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 17: Measured Value Technology

    8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 18: Interfaces

    Analog output/Digital output (switchable) QA/Q2 O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 19: Ssi (Synchronous Serial Interface)

    DE = Device error, AE = Application error 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 20: Rs-422 Interface

    (0x02) and <ETX> (0x03). The first four characters of the data field have a con‐ stant pre-assignment for compatibility reasons. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 21 11.0 10.5 38400 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 22 “Service”. If the password has been changed, the respective hash value must be entered here, "Parameterization via SOPAS ET", page O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 23 Output 1388 corresponds to 5000 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 24 <STX>sAN switchHeaterOn<ETX> --> Response OK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...
  • Page 25 <STX>sWN rs422PeriodicOutputContent 1<ETX> 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 26: Profibus Dp Interface

    Up to 32 users can be interconnected as masters or slaves in one segment. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...
  • Page 27 86, or via the SOPAS ET interface. 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 28 Input and output values count independently of each other. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 29 4 words, 1 byte 0.0, 0.0 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 30 Output 1 byte O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...
  • Page 31 1 byte 37.0 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 32 Free speed resolution 1 ... 1000000 [µm/s] O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...
  • Page 33 Values Alignment laser 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 34 For details, see "Configuring the serial interface", page O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 35 The distance output value of the distance sensor corresponds to the value 0 at the 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 36: Ethernet Interface

    ■ current levels O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...
  • Page 37 33, page 100) 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 38: Transport And Storage

    "Technical data", page 103. ■ O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...
  • Page 39 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 40: Mounting

    O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...
  • Page 41 Figure 9: Anisotropy of the light spot 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 42: Select And Mount The Reflector (Dl1000 Only)

    Tilt of the horizontal axis of the reflector approx. +1°…+3° O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 43: Mounting/Disassembling Additional Filter (Dt1000 Only)

    Unscrew locking screws: 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 44: Placement Of Multiple Distance Sensors

    For the DT1000, observe the following information on minimum distances. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 45 ≥ 0.2 m + 0.004 x s 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 46: Mounting The Alignment Bracket And Distance Sensor

    Insert the distance sensor into the alignment bracket. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 47: Aligning Distance Sensor

    10500 10500 10500 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 48 Figure 16: Align the distance sensor with alignment bracket in the X-direction O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...
  • Page 49 Figure 17: Align the distance sensor with alignment bracket in the Y-direction 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 50: Electrical Installation

    O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 51: Digital Outputs

    High Inactive High 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 52: Analog Output

    Distance value for 20 mA Distance value for 4 mA O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 53: Connecting The Device Electrically

    Cable shield (housing) 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 54 Transmit data negative Receive data negative O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 55: Operation

    8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 56: Menu Groups

    If numerical parameters can be entered or changed, edit buttons appear on the display. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...

  • Page 57: Selection Lists

    Standard buttons refer to buttons that fulfill the same function in every menu. 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 58: Measured Value Displays

    The temperature display shows the current inside temperature of the device. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...

  • Page 59: Operating Time Display

    "Configuring user-defined substitute values", page 70 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 60: Io Interfaces

    "Module 30 - I/O interface QA/Q2", page 35 O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 61: Device Information

    Show parameters and measured values main 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 62 After you have completed the configuration, you must save it in the device permanently by pressing the Save permanent button. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 63: Reference

    0 m/s speed 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 64: Defining The Measurement Cycle Time

    Distance offset: -4500 m to 4500 m O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 65: Defining The Measuring Direction

    2,048 ms 4,096 ms 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 66: Activating/Deactivating The Fog Filter

    Using the average filter deactivates the Kalman filter. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 67: Activating/Deactivating The Kalman Filter

    8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 68: Defining The Echo Selection

    The measuring range limit facing the device (echoes from short distances are ignored): 0.1 ... 1,500 m O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 69: Configuring Signal Level Range Limits

    0 to 1023 cycles 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 70: Defining Substitute Values For "No Echo

    0 m/s -20 m/s to 20 m/s O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 71: Behaviour On Error

    + distance offset. 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 72: Defining The Switching Hysteresis For The Distance Value

    Output potential for inactive switching state: low voltage O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 73: Defining The Switching Window For The Distance Value

    0 m to 1500 m 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 74: Defining The Switching Window Active Status For The Distance Value

    (see "Switching functions", page 16). O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 75: Defining The Monitoring Direction For The Object Speed Value

    "Signal inputs/outputs", page 18). 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 76: Assigning A Switching Event To The Service Functions

    Switching signal after expiration of the delay time for “No echo” O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...

  • Page 77: Defining The Active State For Service Functions

    -4500 m to 4500 m 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 78: Configuring The Switching Input

    Input potential for the active state: high voltage O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 79: Device Menu Group

    Selection of languages indicated on the display. 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 80: Defining Units Of Measure

    Define the display orientation. The display content can be rotated by 180°. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...

  • Page 81: Communication Menu Group

    Define the data transmission rate (baud rate). 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 82: Defining The Rs-422 Data Format

    Select the type of data output using the RS-422 interface. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 83: Defining The Rs-422 Output Cycle Time

    0 ms ... 1,000 ms 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 84: Defining The Rs-422 Data Protocol

    Define the resolution of the speed measured value being output. The speed values are output in multiples of the set resolution. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 85: Defining Ssi Coding

    8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 86: Entering A Profibus Address

    Display of the IP address and manual input in the event of non-dynamically assigned IP address. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 87: Entering A Subnet Mask

    DHCP. Use the arrow buttons to scroll through the individual parameters. 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 88: Info Menu Group

    The different counter readings can be viewed using the arrow buttons. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...

  • Page 89: Deleting The Counter Readings Of Switching Events

    8.7.1 Main menu 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 90: Measurement Menu Group: Basic Settings

    8.7.2 Measurement menu group: Basic settings O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 91: Measurement Menu Group: Expert Settings

    Measurement menu group: Expert settings 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 92: Io Interface Menu Group: Digital Input In1

    8.7.4 IO interface menu group: Digital input In1 O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 93: Io Interface Menu Group: Digital Output Q1

    IO interface menu group: Digital output Q1 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 94: Io Interface Menu Group: Digital Output Q2

    8.7.6 IO interface menu group: Digital output Q2 O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 95: Io Interface Menu Group: Analog Output Qa

    Device menu group 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 96: Communication Menu Group

    8.7.9 Communication menu group O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 97: Info Menu Group

    Info menu group 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 98: Maintenance

    Recommended: At least every 6 months. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 99: Troubleshooting

    Prevent interruption of voltage supply, repeat firmware update. 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 100 Bus errors and system errors are displayed using the BF and SF LEDs. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...

  • Page 101: Information For The Service Case

    8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 102 Separate the recyclable materials by type and place them in recycling containers. ■ O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 103: Technical Data

    “Laser Notice No. 50”, dated June 24, 2007. 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 104 (part number 2088511). O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP...

  • Page 105: Measuring Range Diagrams

    Measurement cycle time in ms 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 106 Upper end of measuring range in m (ft) Measurement cycle time in ms O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...

  • Page 107: Repeatability Diagrams

    Distance in m (ft) 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 108 Typical repeatability in mm (inch) Distance in m (ft) O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 109 Distance in m (ft) 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 110 Figure 37: DT1000 repeatability with 16 ms measurement cycle time Typical repeatability in mm (inch) O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 111 Distance in m (ft) 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 112: Measurement Accuracy Diagrams

    Distance [m] Distance [m] O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 113: Interfaces

    Resolution: 16 bit 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 114: Mechanics/Electronics

    Temperature drift Typ. 0.25 mm/K O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK Subject to change without notice...

  • Page 115: Classifications

    UNSPSC 16.0901 41111613 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...

  • Page 116: Dimensional Drawings

    Figure 43: Device measurements, unit: mm (inch), decimal separator: period O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 117 Figure 45: Alignment bracket with device, unit: mm (inch), decimal separator: period 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 118 Figure 46: Additional filter for high temperature applications, unit: mm (inch), decimal separator: period O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 119 Accessories and where applicable mounting information can be found online at: • www.sick.com/Dx1000 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 120 Printed copies of the license texts are also available on request. O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP 8024560/1A19/2021-06-30 | SICK...
  • Page 121 APPENDIX 8024560/1A19/2021-06-30 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 PROFIBUS DP and DL1000 PROFIBUS DP Subject to change without notice...
  • Page 122 E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com SICK AG | Waldkirch | Germany | www.sick.com...

This manual is also suitable for:

Dl1000 profibus dp

Table of Contents
