6. Secure the mounting arm location by sliding lock pin into the hole. Use the washer and remaining small screw to
secure the lock pin by screwing upwards through the bottom of the hole in the mounting bracket.
7. Set the PIR Sensitivity Settings using the panel or remotely using the Partner Portal or MobileTech app. For
information about setting the PIR Sensitivity Settings, see
The following three options can be set:
Normal
High
Low
Verify and test Image Sensor setup
1. Verify that rules are confirmed via the Partner Portal or on MobileTech app.
◦ Look for the word Yes in the Image Sensor Equipment List in the Rules Confirmed section. Resend rules if
they are not confirmed.
2. Verify RF Coverage by checking that the signal strength is above 40%. The signal strength must be greater than
30% for sensor to function properly.
3. Conduct a walk test and test image captures.
◦ To conserve the customer's monthly image upload quota, automatic alarm uploads are disabled for the first
four hours after any new sensor (Image Sensor or other) is installed into the system. Installers can also test by
requesting image uploads and motion image uploads via MobileTech app. Installers are required to be onsite
to test by running a comm test at the panel.
4. Test night image captures by darkening the room as much as possible (turn off the lights and close the shades).
https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Image_Sensor/Image_Sensor_Version_3/Qolsys_IQ_Pa...
Change Image Sensor sensitivity.
Default setting
More sensitive motion profile with potential higher risk
of false alarm.
Less sensitive profile with pet immunity for pets up to
40 lbs.
