Alarm.Com ADC-IS-100-LP Installation & User Manual

Alarm.com Image Sensor
ADC-IS-100-LP, ADC-IS-100-SL
Product Summary
The Alarm.com Image Sensor (ADC-IS-100-LP,
ADC-IS-100-SL) is a wireless PIR (passive-infrared)
motion sensor with image capture capabilities.
The PIR sensor detects motion by changes of
infrared radiation in the sensor's detection area.
The sensor reports motion activations to the
control panel it is enrolled in. An Alarm.com
Image Sensor enabled GSM module is required
to enroll the ADC-IS-100-LP and ADC-IS-100-SL
into a control panel.
On motion activations, the device can be
configured to capture images. Specific
Alarm.com service plans and hardware are
required for this service.
Compliance
Operation is subject to the following two
conditions:
(1) This device may not cause interference
(2) This device must accept any interference,
including interference that may cause undesired
operation of the device
Changes or modifications not expressly approved
by Alarm.com can void the user's authority to
operate the equipment.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
Installation & User Guide
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
•
Increase the separation between the
•
equipment and receiver.
Connect the equipment into an outlet on a
•
circuit different form that which the
receiver is connected.
Consult the dealer or an experienced
•
radio/TV technician for help.
Installation Guidelines
Adhere to the following guidelines for optimal
performance and false alarm protection:
The ADC-IS-100-LP or ADC-IS-100-SL
should be installed indoors only using
the provided corner or flat wall mount
brackets and mounting arm.
The sensor should be mounted on a flat
wall surface (do not set on shelf) free of
vibrations.
To obtain the maximum coverage area of
40 feet by 40 feet, the sensor should be
mounted at a downward angle as
prescribed in the installation
instructions. Altering mounting height
or angle will change the coverage area.
The sensor should be mounted within
100 feet of the control panel. The range
may be affected by environmental
conditions that vary by installation.
Avoid facing the sensor toward or
between areas that may affect
communication, such as metallic objects
or electronics likely to produce
