Alarm.com Video Doorbell (ADC-VDB770) - Installation Guide
Use this guide to assist with the installation of your VDB770 doorbell camera.
Pre-installation checklist
• ADC-VDB770 and included accessories
• Wire crimping tool
• Wi-Fi connection to broadband (Cable, DSL, or Fiber Optic) internet
• A computer, tablet, or smartphone with Wi-Fi is required if the router does not have the Wi-Fi Protected Setup
(WPS) feature
• Verify that your transformer meets the minimum voltage of 16 VAC and minimum power of 10 VA; specifications are
often written directly on the transformer
• A compatible chime. For more information, see
Important: The ADC-VDB770 requires a service package that supports Video Analytics and has the Doorbell
Cameras add-on. For more information, see
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-...
What types of chimes are compatible with the ADC-VDB770?
What service packages can support enrolling the
ADC-VDB770?.
Updated: Wed, 24 Feb 2021 08:03:20 GMT
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Alarm.Com ADC-VDB770
Summary of Contents for Alarm.Com ADC-VDB770
- Page 1 • A compatible chime. For more information, see What types of chimes are compatible with the ADC-VDB770? Important: The ADC-VDB770 requires a service package that supports Video Analytics and has the Doorbell Cameras add-on. For more information, see What service packages can support enrolling the ADC-VDB770?.
-
Page 2: Installation
Media, iframe, embed and object tags are not supported inside of a PDF. Installation Install the power module 1. Verify that the electricity is turned off at the transformer before installing the power module. Locate your chime box and remove the cover. https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-… Updated: Wed, 24 Feb 2021 08:03:20 GMT... - Page 3 4. Using a crimp tool and the wire connectors provided, connect the wires that were set aside to the straight gray wires of the power module. 5. Affix the power module to the side of the chime using the included adhesive. Replace the chime cover. https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-… Updated: Wed, 24 Feb 2021 08:03:20 GMT...
- Page 4 Note: The power module must be used in every installation regardless of the chime type. The power module is used to prevent the chime from buzzing or humming, and it helps ensure sufficient power is provided to the Alarm.com Video Doorbell.
- Page 5 2. At the installation location, an angled mounting bracket can be used to modify the field of view. Choose a mounting bracket type best suited for your installation setup. Installation scenarios corresponding to mounting bracket types A, B, and C are provided below to guide your decision. https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-… Updated: Wed, 24 Feb 2021 08:03:20 GMT...
- Page 6 3. Thread the existing wires through the mounting bracket. Install the mounting bracket to the wall using the included wall screws (and anchors, if needed for the mounting surface). https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-… Updated: Wed, 24 Feb 2021 08:03:20 GMT...
- Page 7 4. Thread the wire extenders through the backplate. Remove the wire caps. 5. Crimp the two wires coming through the backplate to the existing wires threaded through the mounting bracket. https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-… Updated: Wed, 24 Feb 2021 08:03:20 GMT...
- Page 8 7. Attach the doorbell to the backplate by aligning and pushing together until it clicks into place and the connection is well sealed. 8. Turn the electricity back on. Check that the doorbell camera’s light is flashing white after the boot process is complete. https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-… Updated: Wed, 24 Feb 2021 08:03:20 GMT...
- Page 9 3. On the same device, open a web browser and enter http://vdb770install or 192.168.1.1 in the web address field. Follow the on-screen instructions to add the ADC-VDB770 to the Wi-Fi network. Verify the LED turns solid green, indicating the connection is complete. WPS Mode (alternate) Note: Use WPS mode if you have easy access to the Wi-Fi router and the router has the WPS feature enabled.
- Page 10 1. Add the device to the account by selecting the account in MobileTech, by using the customer Mobile App, or by using a web browser and entering the following web address: www.alarm.com/addcamera. 2. Select the Video Doorbell from the video device list or enter in its MAC address to begin adding the device. The device’s MAC address is located on the included reference card.
-
Page 11: Troubleshooting
2. If issues persist, factory reset the Video Doorbell by pressing and holding the doorbell button until the LED starts blinking red and green (~75s). The device will reboot with factory defaults. Important: If the device was previously installed to an Alarm.com account, it will need to be deleted before it can be installed again. -
Page 12: Additional Resources
Additional resources View the Alarm.com Doorbell Installation Instructional Video today! For more information on accessing Academy Training, see How can I access the Training Center on the Partner Portal?. https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-… Updated: Wed, 24 Feb 2021 08:03:20 GMT...
Need help?
Do you have a question about the ADC-VDB770 and is the answer not in the manual?
Questions and answers
We just moved into a home that has an ADC-VDB770 installed, but the previous owners didn't leave any documentation. How do I get it to work? Thank you.
To set up the Alarm.com ADC-VDB770, follow these steps:
1. Install the Power Module:
- If using a mechanical chime, turn off power at the breaker.
- Open the chime box and take note of wire connections.
- Install the provided power module according to instructions.
2. Mount the Doorbell:
- Mount the ADC-VDB770 at the door.
- Ensure the wiring is properly connected.
3. Power On the Device:
- Restore power. The LED should blink white after booting.
4. Connect to Wi-Fi (AP Mode recommended):
- On a smartphone or computer, connect to the camera’s Wi-Fi (SSID: ADC-VDB770 XX:YY:ZZ).
- Open a browser and go to http://vdb770install or 192.168.1.1.
- Follow on-screen instructions to connect to your Wi-Fi.
- The LED will turn solid green once connected.
5. Alternative: WPS Mode:
- After boot, hold the button for 30–35 seconds until the LED blinks blue.
- Activate WPS on the router.
- If successful, the LED will turn solid green.
6. Account Requirements:
- Your account must have Video Analytics and Doorbell Camera add-ons enabled.
- Contact your alarm monitoring company if needed.
7. Final Checks:
- Ensure the LED is solid green.
- If LED is solid red, press and hold the button until it alternates green and red, then retry setup.
