NUCLEO-H563ZI product information
14.1
Product marking
The stickers located on the top or bottom side of all PCBs provide product information:
•
First sticker: product order code and product identification, generally placed on the main board featuring
the target device.
Example:
Product order code
Product identification
•
Second sticker: board reference with revision and serial number, available on each PCB.
Example:
MBxxxx-Variant-yzz
syywwxxxxx
On the first sticker, the first line provides the product order code, and the second line the product identification.
On the second sticker, the first line has the following format: "MBxxxx-Variant-yzz", where "MBxxxx" is the board
reference, "Variant" (optional) identifies the mounting variant when several exist, "y" is the PCB revision, and "zz"
is the assembly revision, for example B01. The second line shows the board serial number used for traceability.
Parts marked as "ES" or "E" are not yet qualified and therefore not approved for use in production. ST is not
responsible for any consequences resulting from such use. In no event will ST be liable for the customer using
any of these engineering samples in production. ST's Quality department must be contacted prior to any decision
to use these engineering samples to run a qualification activity.
"ES" or "E" marking examples of location:
•
On the targeted STM32 that is soldered on the board (for an illustration of STM32 marking, refer to the
STM32 datasheet Package information paragraph at the
•
Next to the evaluation tool ordering part number that is stuck, or silk-screen printed on the board.
Some boards feature a specific STM32 device version, which allows the operation of any bundled commercial
stack/library available. This STM32 device shows a "U" marking option at the end of the standard part number
and is not available for sales.
To use the same commercial stack in their applications, the developers might need to purchase a part number
specific to this stack/library. The price of those part numbers includes the stack/library royalties.
14.2
NUCLEO-H563ZI product history
Order
Product
code
identification
MCU:
revision "Z"
MCU errata sheet: STM32H563/
NUH563ZI$MR1
H573 and STM32H562 device
errata (ES0565)
Board: MB1404‑H563ZI-C01
14.3
Board revision history
Board reference
Board variant and revision
MB1404
UM3115 - Rev 1
Table 26.
Product history
Product details
STM32H563ZIT6
silicon
Initial revision
Table 27.
Board revision history
H563ZI-C01
Initial revision
www.st.com
Product change description
Board change description
UM3115
NUCLEO-H563ZI product information
website).
Product limitations
No limitation
Board limitations
No limitation
page 36/43
