MIPI20
pin
9
10
11
12
13
14
15
16
17
18
19
20
UM3115 - Rev 1
CN5
GND Ground
NRST Target NRST using SWD protocol or target JTMS (T_JTMS) using JTAG protocol
TgtPwr 5 V target power to the target MCU–To be disconnected (SB84 OFF)
TRACECLK Trace clock
TgtPwr 5 V target power to the target MCU–To be disconnected (SB84 OFF)
TRACED0 Trace Data0
GND Ground
TRACED1 Trace Data1
GND Ground
TRACED2 Trace Data2
GND Ground
TRACED3 Trace Data3
Embedded STLINK-V3EC
Designation
