External power supply input from the USB user connector (5 V, 3 A maximum)

The STM32H5 Nucleo-144 board and shield can be powered from the USB user connector (CN13). To select the
USB user power source, JP2 must be fitted on [9-10] 'USB USER' (refer to
Input power
name
USB USER
UM3115 - Rev 1
External power supply input from the USB user connector (5 V, 3 A maximum)
Table 10. External power source USB user (5 V, 3 A)
Connector pins
CN13
Figure 12. Power supply input from USB user connector (5 V, 3 A)
5V
5V
Host PC
Figure 12 and Table
Voltage Maximum current
5 V
3V3
UM3115
10).
3 A
