Connecting the Cleaning Unit to the 'Robacta
Reamer' Parting Agent Container
Connecting the
NOTE!
cleaning unit to
the 'Robacta Only use the 'Robacta Reamer' parting agent provided by the manufacturer.
Reamer' parting Its composition is specifically tailored for use with the cleaning device. Correct
agent container operation is not ensured when other products are used.
1
Underside of the cleaning unit
1
(1)
5
6
4
Connect the parting agent hose
2
from the parting agent container
to the parting agent atomizer con-
nection socket (1) on the underside
of the cleaning unit
NOTE!
The parting agent injection time must
be set via the robot control.
The selected injection time cannot be
less than 0.5 seconds.
An injection time of ~ 0.7 seconds is
recommended. Depending on the size
of the gas nozzle, the necessary injec-
tion time may vary.
