Screwing the
NOTE!
base unit and
work stand to Only attach the base unit to the foundation with the work stand provided for
the surface that purpose.
(foundation)
NOTE!
Depending on the surface, different mounting materials may be required for
connecting the work stand to the surface.
The mounting materials required for connecting the work stand to the mounting
surface are not supplied with the work stand. The screws that are supplied with
the work stand are not suitable for screwing the work stand to the mounting sur-
face. The installer is responsible for selecting the proper mounting materials.
1
2
Position the work stand (available as an option) on a level, solid, and vibra-
tion-free surface
-
Position the work stand in such a way that the interconnecting hosepack
of the cleaning unit can be connected to the base unit
Tightly screw the work stand to the mounting surface using the selected
mounting materials
Position the base unit on the work
3
stand
Attach the base unit to the work
4
stand with four screws – use the
screws supplied with the base unit
