Operating controls, connections and mechanical
components

General

All functions of the cleaning device are activated via the robot control. For setup
operation, the cleaning process can be triggered manually on the base unit hous-
ing.
NOTE!
Individual images may differ slightly from your device.
However, the function of the operating elements and connections is identical.

Control panel

No.
Func-
tion
(1)
NOTE!
If the capacitors have been charged in the device, they usually discharge auto-
matically as soon as the device is disconnected from the grid.
The discharge time is usually around 1 second.
In the event of an error, the capacitors may not be discharged. In this case, it is
essential to follow the instructions in the section
Error
(2)
28
(1)
Mains voltage indication
Lights up when the device is being supplied with mains voltage
on page 57.
Overtemperature indication
Lights up when the device heats up excessively
(2)
(3) (4)
What to Do in the Event of an
(5)
