Figure 31 - Capacitor Module Features and Indicators
2
1
Item Description
1 Ground screw (green)
2 Module status (MS) connector (relay output)
3 Module status indicator
4
DC bus (DC) connector (under cover)
5
24V control input power (CP) connector
(1) The DC-bus connector ships with a protective knock-out cover that can be removed for use in shared-bus configurations.
(2) The shared-bus connector set for the capacitor module, catalog number 2198-KITCON-CAP1300, is included for connection to
the upstream drive. Replacement kits are also available.

Module Status Connector Pinout

MS Pin Description
1
Module status output
2

Safe Torque Off Connector Pinout

For the hardwired Safe Torque Off (STO) connector pinouts, feature
descriptions, and wiring information, see

Input Power Connector Pinouts

Table 22 - Mains Input Power Connector
IPD Pin Description
Chassis ground
L3
L2 Three-phase input power
L1
Rockwell Automation Publication 2198-UM001M-EN-P - November 2022
Chapter 4
Kinetix 5500 Capacitor Module
Top View
3
2
Kinetix 5500 Capacitor Module
Front View
1
(1) (2)
(2)
Chapter 9
Connector Data and Feature Descriptions
4
5
Signal
MS
MS
beginning on page 157.
Signal
L3
L2
L1
59
