Kinetix 5700 DC-bus Conditioner Module
Catalog Number 2198-DCBUSCOND-RP312
Topic
About the DC-bus Conditioner Module
The 2198-DCBUSCOND-RP312 DC-bus conditioner module is used in applications with all
bus supplies in the following situations:
• Decreases the voltage stress on insulation components in an inverter system with long
cable lengths.
• To extend the DC-bus voltage to another inverter cluster.
See the Kinetix® 5700 Servo Drives User Manual, publication 2198-UM002, for detailed
information on system configurations that include the DC-bus conditioner module.
Before You Begin
Remove all packing material, wedges, and braces from within and around the components. After
unpacking, check the item nameplate catalog number against the purchase order.
The Kinetix 5700 DC-bus conditioner module includes the following accessory items:
• Parts kit containing stud/lug cover with wires, lug-cover bottom plate, hex nuts and
spacers for M8 studs, and 55 mm DC-bus link. Stud cover for systems without wires
attached is installed on each module.
• Wiring plugs for the module status (MS) and 24V DC input power (CP) connectors.
• Flexible bus bars, 2 each.
TIP
Replacement connector sets (catalog number 2198-KITCON-DCBUSCOND) is also available. See the
Kinetix Servo Drives Specifications Technical Data, publication KNX-TD003, for more information.
• These installation instructions, publication 2198-IN016.
Page
1
1
2
6
7
11
