- Page 1 INSTRUCTION MANUAL AIR 78 AIR 79 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M5.0x25 mm BOLT L Wrench 24PCS+1 spare Spanner... - Page 5 PARTS Back panel Left panel Right panel Tray support bar Front panel Wire floor Wheels with brake Wheels without brake 2PCS 2PCS...
- Page 6 PARTS Tray Roof support bar Roof 2PCS...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Attach the back panel Part A to side panel Part B & C by 4XP1 bolts. Attach the tray support bar Part D by 4XP1 bolts. - Page 8 PRODUCT ASSEMBLY Attach the wire floor Part E by 4XP1 bolts. Attach the front panel Part F by 4xP1 bolts.
- Page 9 PRODUCT ASSEMBLY Attach 4 casters Part G & H to the cage.
- Page 10 PRODUCT ASSEMBLY Put in the mat Part I, and slide in the plastic tray Part J. Attach the roof support bar Part L to roof Part K by 4XP1 bolts.
- Page 11 PRODUCT ASSEMBLY Attach the roof by 2XP1 bolts each side. Please use a screwdriver or wrench to tighten all the bolts !
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
