General Information - DEVA Broadcast DB7002 Maintenance And Operation Instruction Manual

DB7002 is a revolutionary solution that combines in a single, high-precision tool the most
important functionalities of two separate types of product. To achieve that, our engineers have
equipped this model with two independent tuners - one for FM and one for DAB/DAB+, allowing
for the device to perform both FM and DAB/DAB+ monitoring in parallel. It provides detailed and
accurate measurement of all of the most important signal parameters and also boasts two loggers
with 24 channels apiece for FM and DAB/DAB+. The recorded information is stored in log files
on an SD card for easy future analysis and can easily be downloaded via a standard FTP client.
As a product that incorporates DAB/DAB+ monitoring capabilities, DB7002 fully meets the
ETSI EN 300 401 DAB standard and offers support for Program Associated Data (PAD), as well
as all standard bitrates and VBR, and automatically displays live metadata.
As an FM monitoring tool, DB7002 also provides powerful signal processing capabilities
through sophisticated DSP algorithms and offers a Loudness Meter, which allows for measurements
to be shown as defined by ITU BS.1770-4 and EBU R128 recommendations.
To make sure the transmission is not interrupted, there are local alarm options and online
notifications via rear-panel alarm GPOs, E-mail and SNMP in case there is audio loss or a change
in the signal.
DB7002 can also be managed without effort. It is easy to program via the front-panel menu or
remotely through your PC, tablet or smart phone via a standard web browser; iOS and Android
devices are also supported. The high-resolution OLED graphical display and the ultra-bright LED
bar graph indicators allow for easy reading of the main signal parameters. A user-friendly front
panel menu in addition to the set of four soft buttons provides easy navigation and quick access to
each function.
DB7002 is definitely a must-have. Its two independent tuners set it apart from any other product,
while its effectiveness and precision make it the perfect monitoring tool.
