SC1™/TC1™ Installation
Manual for Fendt 200 VFP
Varioguide (with Fendt
One, Model Year 2021)
016-5033-270 Rev. B
11/2022
E43866
Copyright 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Raven SC1

  • Page 1 SC1™/TC1™ Installation Manual for Fendt 200 VFP Varioguide (with Fendt One, Model Year 2021) 016-5033-270 Rev. B 11/2022 E43866 Copyright 2022...
  • Page 2 Raven systems, or products used as components of systems, which rely upon the reception of these signals or availability of these services. Raven Industries accepts no responsibility for the use of any of these signals or services for other than the stated purpose.
  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Important Information..................1 Safety ....................................1 Displays and Control Consoles ............................1 Electrical safety ..................................2 Touch Screen .................................... 2 Recommendations and Best Practices ........................ 2 Harness Routing ..................................2 Chapter 2 Introduction......................5 Installation Best Practices ............................5 Recommendations .................................
  • Page 4 Table of Contents SC1™/TC1™ Installation Manual for Fendt 200 VFP Varioguide (with Fendt One, Model Year 2021)
  • Page 5: Chapter 1 Important Information

    • Do not operate this Raven system or any agricultural equipment while under the influence of alcohol or an illegal substance. • Be alert and aware of surroundings and remain in the operator seat at all times when operating this Raven system.
  • Page 6: Electrical Safety

    • Do not connect the power leads to the battery until all system components are mounted and all electrical connections are completed. • Always start the machine before initializing this Raven system to prevent power surges or peak voltage. • To avoid tripping and entanglement hazards, route cables and harnesses away from walkways, steps, grab bars, and other areas used by the operator or service personnel when operating or servicing the equipment.
  • Page 7: Harness Routing

    The word “harness” is used to describe any electrical cables and leads, both bundled and unbundled. Use the following guidelines and recommendations when connecting and routing harnesses while installing or maintaining this Raven system: • Leave protective caps/covers over harness connectors until needed to avoid dirt and moisture from contaminating electrical circuits.
  • Page 8 • Remove visible surface water from electrical components and connections using pressurized air or an aerosol cleaning agent. Allow components to dry thoroughly before reconnecting cables. SC1™/TC1™ Installation Manual for Fendt 200 VFP Varioguide (with Fendt One, Model Year 2021)
  • Page 9: Chapter 2 Introduction

    I NTRODUCTION CHAPTER C H A P T E R 2 This system is designed to provide hands-free steering of the machine via GNSS (Global Navigation Satellite Systems) coordinates. This manual applies to the following machines. Make. Fendt Model. 200 VFP Gen 3 Varioguide Ready with Fendt One FIGURE 1.
  • Page 10: Installation Best Practices

    RECOMMENDATIONS Before installing the SC1/TC1 system, park the machine where the ground is level, clean, and dry. Bleed pressure from the hydraulic system and leave the machine turned off for the duration of the installation process.
  • Page 11: Kit Components

    KIT COMPONENTS This section contains a list of the components that are included in the SC1/TC1 kit. Before beginning the system installation, compare the items in the kit with the components on this list. If you have questions about the kit, contact your Raven dealer.
  • Page 12: Updates

    Applied Technology Division website: https://portal.ravenprecision.com Sign up for e-mail alerts to receive notifications when updates for your Raven products are available on the Raven website. At Raven Industries, we strive to make your experience with our products as rewarding as possible.
  • Page 13 FIGURE 1. Roof Cover Location and Device Plate 3. Disconnect and remove the AGCO Guidance Controller from the plate. 4. Mount the SC1/TC1 ECU to the plate in the location from which the OEM guidance controller was removed. NOTE: Mount the 700S and Slingshot Field Hub onto the plate as shown in the figure below. Review the InstallMount the 500S andor 700S section on page 14 and Install Slingshot Field Hub section on page 13 for additional assistance.
  • Page 14 CHAPTER 3 5. Connect the SC1/TC1 cable for Fendt 200 gen3 (P/N 115-4010-239) to the SC1 ECU, the 700S receiver, and the Slingshot Field Hub. NOTE: Route the X4250 connector on the SC1/TC1 cable toward the back of the roof. This connector will connect to the Fendt roof port as described in the MountConnect the Harness section on page 10.
  • Page 15: Chapter 3 Installation

    INSTALLATION FIGURE 4. OEM X3058 Connector Location NOTE: If installed on the machine, the AGCO Connect module will be connected to this plug. 3. Disconnect any existing components from the plug and connect the Fendt 200 gen3 V-Bus cable (P/N 115- 4010-241) to the X3058 connector.
  • Page 16 FIGURE 6. Reverse side of the OEM X4250 Connector MOUNT THE 500S OR 700S SC1/TC1 may be used with either the Raven 500S or 700S GNSS receivers or a CR12 or Viper 4 field computer with internal GPS. The following items outline some best practices or suggestions for mounting the receiver:...
  • Page 17: Install Slingshot Field Hub

    INSTALLATION FIGURE 8. Protective Cap INSTALL SLINGSHOT FIELD HUB The following items outline some best practices or suggestions for mounting the Slingshot Field Hub: NOTE: For detailed installation instructions, review the manual provided with the Field Hub. • The GPRS/UMTS antennas are equipped with a magnetic base and must be placed on top of the cabin.
  • Page 18 The GPRS/UMTS antennas should be mounted on separate roof brackets and away from the GNSS antenna. NOTE: Review the Recommendations and Best Practices section on page 2 for more information. SC1™/TC1™ Installation Manual for Fendt 200 VFP Varioguide (with Fendt One, Model Year 2021)
  • Page 19 INSTALLATION FIGURE 12. GPRS/UMTS Mounted MOUNT THE CR7™ OR CR12™ The following items outline some best practices or suggestions for mounting the Raven field computer: NOTE: For more installation instructions, review the manual provided with the field computer. • Always ensure the terminal is placed in the most appropriate position facing the driver seat for easy access and use.
  • Page 20 • Mount the 9-pin ISOBUS connector to the panel mount connector in the cabin of the machine. • Mount the 3-pin power connector. SC1™/TC1™ Installation Manual for Fendt 200 VFP Varioguide (with Fendt One, Model Year 2021)
  • Page 21 INSTALLATION • Route the harness to the field computer. FIGURE 15. ISOBUS and Power Connector Installation: Connect the Field Computer Harness...
  • Page 22: Activate Automatic Steering

    Engage/Disengage automated steering 2. After a successful self-test of the steering system, the LED will activate and SC1/TC1 automated steering can be activated by pressing the auto-steering button on the joystick. SC1™/TC1™ Installation Manual for Fendt 200 VFP Varioguide (with Fendt One, Model Year 2021)
  • Page 23: System Drawings

    INSTALLATION SYSTEM DRAWINGS FIGURE 17. SC1/TC1 with CR7 System Diagram for Fendt Varioguide with Fendt One (P/N 054-5033-270 Rev. A) Installation: System Drawings...
  • Page 24 CHAPTER 3 FIGURE 18. SC1/TC1 with CR12 System Diagram for Fendt Varioguide w/ Fendt One(P/N 054-5033-271 Rev. A) SC1™/TC1™ Installation Manual for Fendt 200 VFP Varioguide (with Fendt One, Model Year 2021)
  • Page 25 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
  • Page 26 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
  • Page 27 WHAT IS NOT COVERED BY THE EXTENDED WARRANTY? Raven Industries will not assume any expense or liability for repairs outside our facility without written consent. Raven Industries is not responsible for damage to any associated equipment or products and will not be liable for loss of profit, labor, or other damages.
