Raven TC1 Installation Manual

For buhler versatile row crop steerready (my2015 & newer)
Hide thumbs Also See for TC1:

Advertisement

Quick Links

TC1/HDU Installation
Manual for Buhler
Versatile Row Crop Steer-
Ready (MY2015 & Newer)
016-5031-103 Rev. B
11/2019
E33670
Copyright 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Raven TC1

  • Page 1 TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer- Ready (MY2015 & Newer) 016-5031-103 Rev. B 11/2019 E33670 Copyright 2019...
  • Page 2 Raven systems, or products used as components of systems, which rely upon the reception of these signals or availability of these services. Raven Industries accepts no responsibility for the use of any of these signals or services for other than the stated purpose.
  • Page 3: Table Of Contents

    ................................. 4 Point of Reference .................................. 5 Kit Contents ................................... 5 Chapter 3 Cab Component Installation................7 Install the TC1 and HDU Nodes ..........................7 Mount the TC1 and HDU Nodes ............................7 Install the Node Harness ............................9 Bulkhead Connection ................................10 Connect HDU and TC1 ...............................11...
  • Page 4 Table of Contents TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer-Ready (MY2015 & Newer)
  • Page 5: Important Safety Information

    • Do not use hands to check for leaks. Hydraulic fluid under pressure can penetrate the skin and cause serious injury or death. • When starting the machine for the first time after installing TC1, be sure that all persons stand clear in case a hose has not been properly tightened.
  • Page 6: Hydraulic Safety

    CAUTION HYDRAULIC SAFETY • Raven Industries recommends that appropriate protective equipment be worn at all times when working on the hydraulic system. • Never attempt to open or work on a hydraulic system with the equipment running. Care should always be taken when opening a system that has been previously pressurized.
  • Page 7: Chapter 2 Introduction

    I NTRODUCTION CHAPTER C H A P T E R 2 This manual applies to the following machines. For future reference, write your serial number in the space below. MAKE: Buhler Versatile MODEL: Row Crop 265, 295, 315, 335, 365 YEAR: 2015 &...
  • Page 8: Updates

    Thank you for your time. PREPARING FOR INSTALLATION Before installing the TC1 system, park the machine where the ground is level, clean, and dry. Bleed pressure from the hydraulic system and leave the machine turned off for the duration of the installation process.
  • Page 9: Point Of Reference

    This section contains a list of the components that are included in the TC1 kit. Before beginning the TC1 installation, compare the items in the TC1 kit with the components on this list. If you have questions about the kit, contact your Raven dealer.
  • Page 10 CHAPTER 2 TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer-Ready (MY2015 & Newer)
  • Page 11: Cab Component Installation

    INSTALLATION INSTALL THE TC1 AND HDU NODES MOUNT THE TC1 AND HDU NODES 1. Mount the TC1 (P/N 063-0174-070) and the HDU (P/N 063-0173-887) nodes to the cab bracket (P/N 107-0172- 648). FIGURE 1. TC1 and HDU Node Mounting Bracket...
  • Page 12 4. Remove the two brass bolts securing the bracket with the 2 round connectors. 5. Place the node mounting bracket assembly under the panel latch bracket. 6. Secure with the supplied M6x20mm bolts. FIGURE 3. Node Mounting Location After Installation TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer-Ready (MY2015 & Newer)
  • Page 13: Install The Node Harness

    CAB COMPONENT INSTALLATION INSTALL THE NODE HARNESS FIGURE 4. 6-Pin Deutsch Connector on Node Harness 1. Connect the PWR/ENABLE 6-pin Deutsch connector to the mating connector on the machine harness. FIGURE 5. Machine Ground Bus Bar 2. Locate the machine ground bar on the right side of the compartment. 3.
  • Page 14: Bulkhead Connection

    9. Loop and tie-off the REMOTE SWITCH cable connection, securing it with plastic cable ties as necessary. BULKHEAD CONNECTION 1. Remove machine bulkhead connector and insert round connector in the removed bulkhead location. FIGURE 7. Bulkhead Connection TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer-Ready (MY2015 & Newer)
  • Page 15: Connect Hdu And Tc1

    CAB COMPONENT INSTALLATION CONNECT HDU AND TC1 1. Connect the 12-pin Deutsch connectors to the mating receptacles on the respective nodes. NOTE: Nodes are keyed to prevent connecting matching colors to the wrong node. 2. Connect the steering lockout switch to master switch assembly (PN 063-0173-961).
  • Page 16: Install The Valve Harness

    1. Connect the round 21-pin connector on the valve harness (P/N 115-4001-159) to the mating bulkhead connector under the machine cab. 2. Route the valve harness toward the existing valve located under the cab near the right wheel. TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer-Ready (MY2015 & Newer)
  • Page 17 CAB COMPONENT INSTALLATION FIGURE 11. TRANSDUCER and VALVE Connections TRANSDUCER Connection (Transducer Not Visible) VALVE Connection 3. Connect the TRANSDUCER connector to the pressure transducer installed in Port PS of the valve. 4. Connect the VALVE connector to the open 4-pin Deutsch port on the PVES valve. FIGURE 12.
  • Page 18: System Diagrams

    CHAPTER 3 SYSTEM DIAGRAMS FIGURE 13. Valve and Node Harness Wiring Diagram TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer-Ready (MY2015 & Newer)
  • Page 19 Index Cab Component Installation Installing the Foot Switch Installing the Node Installing the Node Harness Installing the Valve Harness System Diagrams Electrical Safety Hydraulic Safety Important Safety Information Electrical Safety Hydraulic Safety Introduction Kit Contents Preparing for Installation Point of Reference 5 Recommendations 4 Updates Kit Contents...
  • Page 20 Index TC1/HDU Installation Manual for Buhler Versatile Row Crop Steer-Ready (MY2015 & Newer)
  • Page 21 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
  • Page 22 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
