Raven SC1 Installation Manual

Hdu for case ih patriot 3xx0 (steering ready, model year 2010-2016)
Hide thumbs Also See for SC1:
Table of Contents

Advertisement

Quick Links

Download this manual
Raven SC1™ HDU
Installation Manual for
Case IH Patriot 3XX0
(Steering Ready, Model
Year 2010-2016)
016-5032-127 Rev. C
3/2020
E35208
Copyright 2019, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC1 and is the answer not in the manual?

Questions and answers

Related Manuals for Raven SC1

Summary of Contents for Raven SC1

  • Page 1 Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016) 016-5032-127 Rev. C 3/2020 E35208 Copyright 2019, 2020...
  • Page 2 Raven systems, or products used as components of systems, which rely upon the reception of these signals or availability of these services. Raven Industries accepts no responsibility for the use of any of these signals or services for other than the stated purpose.

  • Page 3: Table Of Contents

    Cab Component Installation................15 Install the GPS Receiver Cable ..........................15 Install the Hydraulic Drive Unit (HDU) ......................16 Install the HDU Harness ..............................16 Install the SC1 ................................17 Install the CAN Bridge Cable - If Applicable ......................18 Mount the HDU ..................................19 Routine Operation ..............................
  • Page 4 Table of Contents Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)

  • Page 5: Important Information

    • Do not operate this Raven system or any agricultural equipment while under the influence of alcohol or an illegal substance. • Be alert and aware of surroundings and remain in the operator seat at all times when operating this Raven system.

  • Page 6: Hydraulic Safety

    • Do not connect the power leads to the battery until all system components are mounted and all electrical connections are completed. • Always start the machine before initializing this Raven system to prevent power surges or peak voltage. • To avoid tripping and entanglement hazards, route cables and harnesses away from walkways, steps, grab bars, and other areas used by the operator or service personnel when operating or servicing the equipment.

  • Page 7: Recommendations And Best Practices

    The word “hose” is used to describe any flexible, fluid carrying components. Use the following guidelines and recommendations when connecting and routing hoses while installing or maintaining this Raven system: • Leave protective caps/covers over hose ends until connecting the end into the hydraulic system to help prevent contaminants from entering the system.
  • Page 8 • Remove visible surface water from electrical components and connections using pressurized air or an aerosol cleaning agent. Allow components to dry thoroughly before reconnecting cables. Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)

  • Page 9: Chapter 2 Introduction

    SC1 HDU system. PREPARING FOR INSTALLATION Before installing the SC1 HDU system, park the machine where the ground is level, clean, and dry. Turn off the machine and leave it turned off for the duration of the installation process. During the installation process, follow good safety practices. Be sure to carefully read the instructions in this manual as you complete the installation process.
  • Page 10 Applied Technology Division web site: https://portal.ravenprecision.com The Raven Service Tool and a laptop PC are required to perform software updates of the Raven Rate Control Module. Refer to the Raven Service Tool Operation manual for additional assistance with updating the Raven Rate Control Module.

  • Page 11: Kit Contents

    KIT CONTENTS This section contains a list of the components that are included in the SC1 HDU kit. Before beginning the system installation, compare the items in the kit with the components on this list. If you have questions about the kit, contact your Raven dealer.
  • Page 12 HAPTER FIGURE 2. Wheel Angle Sensor Kit (P/N 117-0192-049 Rev. E) Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)

  • Page 13: Chapter 3 Wheel Angle Sensor Installation

    W HEEL ANGLE SENSOR CHAPTER C H A P T E R 3 INSTALLATION ASSEMBLE THE WHEEL ANGLE SENSOR (WAS) FIGURE 1. WAS Base-End Rod-End of Sensor of Sensor 1. Install the M10 universal ball mounts (P/N 103-0001-029) and M10 jam nuts on both ends of the linear WAS (P/ N 416-0001-052).
  • Page 14 10. Tighten the nuts to ensure the small WAS mounting bracket is installed securely. 11. Install a 0.406” ID x 0.750” OD x 0.375” long spacer (P/N 107-0172-037) on the end of the protruding hex bolt. Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)
  • Page 15 WHEEL ANGLE SENSOR INSTALLATION FIGURE 4. Rod-End of WAS Installed on Rod-End of Steering Cylinder M10 x 1.5 Lock Nut (P/N 312-4000-208) Rod-End of M10 Universal Ball Mount (P/N 103-0001-029) 12. Install the ball mount on the rod-end of the WAS assembly on the installed hex bolt and secure it using an M10 x 1.5 lock nut.
  • Page 16 FIGURE 7. Machine’s AUTO Yaw Connection 18. Disconnect the machine’s existing X-716 connector located near the AutoSense Sensor and plug in the mating connector on the WAS adapter cable. Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)
  • Page 17 WHEEL ANGLE SENSOR INSTALLATION FIGURE 8. WAS Connection 016-5032-127 Rev. C...
  • Page 18 HAPTER Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)

  • Page 19: Cab Component Installation

    2. Connect one end of the installation cable into the 600S/700. 3. Connect the other end of the installation cable into the roof bulkhead connector. 4. On the SC1 harness, remove pin #12 from the gray SC1 connector and populate it in pin #9 of the gray SC1 connector.

  • Page 20: Install The Hydraulic Drive Unit (Hdu)

    8. Inside the cab, connect the 40-pin connector of the HDU harness to the machine’s NAV CONNECTOR 1 connection. 9. Connect the 2-pin ENABLE connector to the machine engage switch. Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)

  • Page 21: Install The Sc1

    FIGURE 5. HDU Harness Cable Installed on HDU 10. Install the two rectangular connectors of the HDU harness into the mating ports of the HDU. 11. Install the two rectangular connectors of the HDU harness into the mating ports of the SC1 (P/N 063-0173-990). INSTALL THE SC1 1.

  • Page 22: Install The Can Bridge Cable - If Applicable

    NOTE: It may be necessary to drill the holes out to install the SC1 mounting bracket. 5. Reinstall the auxiliary power port on the studs of the SC1 mounting bracket, utilizing the nuts provided in the kit. NOTE: The SC1 node must be mounted in a horizontal orientation.

  • Page 23: Mount The Hdu

    CAB COMPONENT INSTALLATION 3. Connect the other end of the CAN bridge cable to the mating connector of the Hawkeye™ harness cable. MOUNT THE HDU FIGURE 8. HDU Installed on HDU Mounting Bracket 1. Install the HDU (P/N 063-0173-887) on the HDU mounting bracket (P/N 107-0172-543) using two 1/4”-20 flanged lock nuts (P/N 312-1001-168).

  • Page 24: Routine Operation

    Locate and identify the machine master switch on the control panel and the foot switch on the cab floor as they are required for the SC1 system operation. Refer to the SC1 Calibration & Operation Manual (P/N 016-4010-005) for instructions on Calibrating the SC1 system, adjusting system settings, and system operation.

  • Page 25: System Diagram

    CAB COMPONENT INSTALLATION SYSTEM DIAGRAM FIGURE 12. SC1/HDU Cabling for Case IH Patriot 3xxx (2010-2016, Steer Ready) 016-5032-127 Rev. C...
  • Page 26 HAPTER Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)
  • Page 27 Index Cab Component Installation Installing the Hydraulic Drive Unit (HDU) 16, 18 Installing the HDU Harness 16 Mounting the HDU 19 Installing the SC1 Tee Cable Introduction Kit Contents Preparing for Installation Point of Reference 5 Recommendations 5 Updates Kit Contents...
  • Page 28 Index Raven SC1™ HDU Installation Manual for Case IH Patriot 3XX0 (Steering Ready, Model Year 2010-2016)
  • Page 29 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
  • Page 30 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility.
