3.0 U T E
SING HE LLIPTICAL
The E5x has been designed for users of all fitness levels. The E5x has linked upper and
lower body motion designed to give a complete low impact body workout. The stride length
is 21" long and over 8" of lift to accommodate even the tallest user.
The E5x has wide pedals and sturdy handrails for easy mounting. After stepping on the
Elliptical Total Body, face the console, hold on to the center handrail the left and right
upper body grips. Use pedaling motion similar to a bike to begin exercising. Follow instruc-
tions to program your favorite workout.

3.1 PAUSING THE UNIT

Your console has the ability to have a 30 second pause feature. On the back of the console
is a battery cover. If the pause feature is not working try replacing the 9 volt battery by
removing the screw and remove the battery cover. Replace the battery and cover.

3.2 CONSOLE DESCRIPTION

U.S Market
T B
OTAL ODY
International Markets
PROGRAMS Simple program view and selection buttons. MATRIX Elliptical total bodys fea-
ture seven programs.
START/QUICK START One Touch Quick Start and Start any time during preference selec-
tion.UP/DOWN Easy information and level selection.
ENTER/SELECT SCREEN/RESET This multi-function button enters information when set-
ting up programming options, toggles information displayed and if held down for 5 seconds
resets the Elliptical total body to Start-up mode.
DISPLAY VIEW These three buttons allow the user to customize the way the unit's lights are
displayed.
* ENTERTAINMENT Control the CHANNEL and VOLUME of your attached TV or entertain-
ment system. (Must have Fit Connexion™ or entertainment source connected).
* HEAD PHONE JACK Located at the base of the console, just plug in a headset and use
the ENTERTAINMENT buttons to adjust VOLUME. (Must have Fit Connexion™ or enter-
tainment source connected).
( * )ONLY FOR INTERNATIONAL MARKETS.
3
