2.1 USING MANAGER PERFERENCE MODE
Your MATRIX Elliptical total body is designed to allow you to cutomize settings for your pref-
erences and diagnostics. The Manager Pereference Mode can only be accessed while the
Elliptical total body is powered up. Folllow the instructions to adjust the Elliptical total body
computer for your desired setting.
Power up the Elliptical total body and Hold the UP and DOWN arrow keys for 3 sec-
STEP 1
onds. The word Manager will apperar in the alphanumeric window and will enter
into the Manager Preference Setting automatically after 3 seconds. Continue to
pedal until finished.
Select information you would like to view or change from the following list, by using
STEP 2
the UP or DOWN arrows. Press ENTER to select.
Manger preference mode will allow you to view and set the following.
DISPLAY CODE: INFORMATION USER DEFINABLE
Manager P0: Maximum program time
P1: Default time
P2: Default level
P3: Default weight
P4: Speed
P5: Machine
P6: TV IR
P7:Cardio Entertainment
P8: Accumulated Distance
P9: Accumulated Time
P10: Software Version
STEP 3 Use UP or DOWN arrows to increase or decrease values.
STEP 4 Press START to save and enter selected values and exit to STEP 2.
STEP 5 Exit by pressing Start. Screen will reset to Start up.
DEFAULT VALUE MIN. MAX.
Y 95 min 5 95
Y 20 min 5 95
Y L1 L1 L20
Y 150 lbs 80 lbs 400 lbs
Y Miles Miles KM
Y BI BI RE,EL
Y On On OFF
Y On On OFF
2.0 U

2.2 SELECTING US OR METRIC

Follow the instructions above. Select P4 speed. Select miles or kilometers according to your
location. The distance and weight will automatically be adjusted.

2.3 USING CSAFE

Matrix is the leading in entertainment availability. On the back of the console are three RJ45
receptacles. They are marked CSAFE IN, CSAFE OUT, and ENTERTAINMENT.
Use the csafe in to plug in an csafe device using the RJ45 connector csafe out allows csafe
products to be daisy chained together from one unit to the next. The connection is as fol-
lows;
UNIT 1
CPU
CSAFE IN
CSAFE OUT
2
M P
SING ANAGER ERFERENCED
UNIT 2
UNIT 3
CSAFE IN
CSAFE OUT
CSAFE IN
M
ODE
