Wiring diagram
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Black PTS Button Conn.
(at PTS switch)
Black
ENGINE
START
Connector
5
4
3
2
STOP
10
9 8 7 6
(-) PTS:
Pink, pin 5
White Conn.
(at Main Body ECU)
Autolight:
Green, pin 8
20
22 23
27
29
8
10
12
13 14 15 16 17 18
Cut
2
5
(-) Unlock:
Violet, pin 2
White conn.
(at dash fuse box)
1
(+) 12V:
Blue, pin 1
8
933.TL8 2.32.195.3 2018 Lexus RX 450h (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Refer to the
Starter disable connection
section for relay and
connector details.
1
(-) Lock:
Pink, pin 29
Yellow, pin 33
56
14
53
33
19
36
HS CAN High:
Lt. Blue, pin 6
Gateway ECU
10
9
8
7
6
5
4
3
2
1
(behind the glove box)
24
23
22212019 1817 1615 1413
12
11
HS CAN Low:
White, pin 21
Hood Pin
Siren
Autolight Interrupt (conn. side): Blue/White: 1
Telematic Interr. (conn. side): White/Brown: 4
Cut
Telematics Interr.:
(-) SLP:
Gray, pin 4
Plug 2A
6
(white conn. rear of
dash fuse box)
Black Steering Lock conn.
1
(at steering lock conn.)
HS CAN Low: Tan: 1
A
this installation.
HS CAN High: Tan/Black: 2
(-) GWA Output: Blue/White: 2
Do not insert 15A fuse
(-) Lock Output: Dk. Green/Black: 3
(-) Unlock Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
Autolight Interrupt (vehicle side): Blue: 3
Telematic Interr. (veh. side): White: 5 & 11
(+) 12V Input: Red: 6 & 12
(-) Ground: Lt. Green/Red: 7
(-) SLP Output: Lt. Green: 8
(-) Ground: Black: 10
).
module can also be used for
Do not insert 15A fuse
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
