3. Connection of components

Please connect the components as shown on below plan.
Connection
hose
(ecom-DP –
Cross piece)
ecom-DP
Swagelok-
screw connec-
tions
Hose 2
(Gas system – Cross piece)
Plug for not
necessary hose
1. Please use for the pressure check only diffusion-close hoses!
2. For usual pressure measurements also not diffusion-close
material like e.g. silicone may be used.
3. A silicone hose can be pushed directly over the quick
connection.
If remounting the Swagelok-screw connections, please turn
6
Connection
hose 2
the nut firmly with your fingers and another 1/4 revolution
Connection
Shut-off valve
Cross piece
Quick connections
Plug for not necessary
connection at cross piece
with a wrench!
Hose 1
(Gas system –
Cross piece)
hose 1
Compres-
sed-air ball
