Step 3. Check Record/Snopshot, click on Save. System prompts it is successfully saved.
Step 4. Check Record Schedule/Snapshot Schedule interface, click on setup next to Holiday, refer to
setup of Monday to Sunday.
Step 5. Complete setup of holiday, then it records/snapshots according to date in holiday schedule.

5.4.2 Destination

5.4.2.1 Path
The destination interface is shown as in
Path can config record and snapshot storage path. There are three options: Local, FTP and NAS. You
can only select one mode. System can save according to the event types. It is corresponding to the
three modes (general/motion/alarm) in the Schedule interface. Please check the box to enable the save
functions.
Note: Only device supports SD card has local.
Please refer to the following sheet for detailed information.
Parameter Function
Event
Type
Local
FTP
NAS
5.4.2.2 Local
The local interface is shown as in
Here you can view local Micro SD card or NAS disk information. You can also operate the read-only,
write-only, hot swap and format operation.
Figure 5-
It includes: scheduled, motion detect and alarm.
It saved in the SD card.
It saved in the FTP server.
It saved in NAS disk.
Figure 5-
57
Figure 5- 57
58.
