Eclipse Security ECL-IP3D50MV Manual page 76


Yellow color stands for the motion detect record/snapshot.

Red color stands for the alarm record/snapshot.
Step 5. In snapshot interface, click on OK. System prompts it is successfully saved.
5.4.1.3 Holiday Schedule
Holiday schedule can set specific date as holiday.
Step 1. Click on Holiday Schedule tab, see
Step 2. Select date to set as holiday. The selected date will be highlighted in yellow.
Figure 5- 55
Figure 5-
.
Figure 5- 56
72
