Please refer to the following sheet for detailed information.
Parameter
SNMP Version
SNMP port
Community
Read community
Write community
Trap address
Trap
Trap Address
Trap Port
Figure 5- 27
Function
Check SNMP v1, device only process v1 info.
Check SNMP v2, device only process v2 info.
Check SNMP v3, can set username, password and
encryption method. Server calibrate corresponding
username, password and encryption method too access
device and v1/v2 are unavailable.
The listening port of the proxy program of the device. It is a
UDP port not a TCP port. The value ranges from 1 to 65535.
The default value is 161
It is a string, as command between management and proxy, ,
defining a proxy, and a manager's authentication.
Read-only access to all SNMP targets, default is public.
Note: Only number, letter, _, and – supported.
Read/write access to all SNMP targets, default is private.
Note: Only number, letter, _, and – supported.
The destination address of the Trap information from the
proxy program of the device.
SNMP trap is a proxy message sent to admin as important
event notice or status change.
Address where to send Trap message.
Port which send Trap message, default is 162, range
1~65535.
52
