5.2.1 TCP/IP

The TCP/IP interface is shown as in
DHCP. IPv6 supports static IP only. When user manually modify IP address, WEB will automatically
jump to the new IP address.
Please refer to the following sheet for detailed information.
Parameter
Host Name
Ethernet Card
Mode
Mac Address
IP Version
IP Address
Figure 5-
. It supports IPv4 and IPv6. IPv4 supports static IP and
Figure 5- 18
Function
It is to set current host device name. It max supports 15
characters.
Please select the Ethernet port. Default is wired.
Please note you can modify the default Ethernet card if there is
more than one card. .
Please note the device needs to reboot to activate the new
setup once you modify the default setup.
There are two modes: static mode and the DHCP mode. Select
DHCP mode, it auto searches IP, and you cannot set IP/subnet
mask/gateway. Select static mode, you must manually set
IP/subnet mask/gateway.
It is to display hose Mac address.
It is to select IP version. IPV4 or IPV6.
You can access the IP address of these two version.
Please use the keyboard to input the corresponding number to
modify the IP address and then set the corresponding subnet
mask and the default gateway.
43
