ECL-IP3D50MV
Manual
Version 1.0.1F
i

Advertisement

Table of Contents
loading

Related Manuals for Eclipse Security ECL-IP3D50MV

Summary of Contents for Eclipse Security ECL-IP3D50MV

  • Page 1 ECL-IP3D50MV Manual Version 1.0.1F...

  • Page 2: Table Of Contents

    Table of Contents Network Config ..........................1 Network Connection ..................... 1 Log in ..........................1 Live ..............................7 Encode Setup ........................ 7 System Menu ......................... 8 Video Window Function Option .................. 8 Video Window Setup ....................9 2.4.1 Image Adjustment ..................... 9 2.4.2 Original Size ......................
  • Page 3 5.1.2 Video ........................35 5.1.3 Audio ........................41 Network ......................... 42 5.2.1 TCP/IP ........................43 5.2.2 Connection ......................44 5.2.2.1 Connection ......................44 5.2.3 PPPoE ........................46 5.2.4 DDNS ........................47 5.2.5 IP filter ........................49 5.2.6 SMTP （e-mail) ..................... 49 5.2.7 UPnP ........................
  • Page 4 Important The following functions are for reference only. Some series products may not support all the functions listed below.

  • Page 5: Network Config

    1 Network Config 1.1 Network Connection Figure 1- 1 Figure 1- 2 Network camera and PC connection mainly has two ways, see Figure 1- 1 Figure 1- 2 Before you access network camera via the Internet, you need to have its IP address. User can use quick config tool to search IP of the network camera.
  • Page 6 Input your IP address here Figure 1- 3 Figure 1- 4 The login interface is shown as below. See Please input your user name and password. Default factory username is admin and password is admin. Note: For security reasons, please modify your password after you first login.
  • Page 7 Figure 1- 4 Figure 1- 5 If it is your first time to login in, you may see the interface shown as in Figure 1- 5...
  • Page 8 Click on “Please click here to download and install the plug-in”. The system pops up warning information Figure 1- 6 to ask you whether run or save this plug-in. See Figure 1- 6 You must either run or save the file to local and install it. Follow the following steps. Click on run, you Figure 1- 7 Figure 1- 8 will see...
  • Page 9 Figure 1- 7...
  • Page 10 Figure 1- 8 When plug-in installation completes, the installation page closes automatically. The web-end will refresh automatically, and then you can view video captured by the camera.

  • Page 11: Live

    2 Live Figure 2- 1 After you logged in, you can see the live monitor window. See Figure 2- 1 There are four sections:  Section 1: Encode setup bar  Section 2: System menu  Section 3: Window function option bar ...

  • Page 12: System Menu

    Parameter Function Streaming media protocol connection, under main stream config, Main stream monitor video or not. Generally for storage and monitor. Streaming media protocol connection, under sub stream 1 Sub (Extra) config, monitor video or not. When network bandwidth is stream 1 insufficient, it substitutes main stream for monitoring.

  • Page 13: Video Window Setup

     When the video is in the original status, click it you can Zoom in select any zone to zoom in. In the non-original status, you can drag the zoom-in zone in specified range. Right click mouse to restore previous status. ...

  • Page 14: Original Size

    Figure 2- 6 for image adjustment. Figure 2- 6 Click this button to display/hide image control interface. Click it to open picture setup interface. This interface is on the top right pane. Please refer to the following sheet for detailed information. Parameter Function Video...

  • Page 15: Width And Height Ratio

    Click it to go to full-screen mode. Double click the mouse or click the Esc button to exit the full screen. 2.4.4 Width and Height Ratio Click it to restore original ratio or suitable window. 2.4.5 Fluency Adjustment There are three levels of fluency for you to select (real-time, normal, fluent). The default is normal. 2.4.6 Focus zoom Click this button and the focus zooming interface appears on the right of preview interface, as shown in figure 2-7, click left mouse button to adjust focus zooming configuration.
  • Page 16 Parameter Function Adjust the sharpness of the lens by clicking or long pressing“+”、“-” buttons. Focus Step length is used to adjust the length of one step with one click. Click to adjust the image definition automatically. Auto- Note: focus Other lens operations are not allowed during the process of auto-focus. Reset the lens to zero position to eliminate the accumulative error of lens.

  • Page 17: Ptz Control

    3 PTZ Control Please note only some series product support PTZ function. Before PTZ operation, please make sure you have properly set PTZ protocol. (Please refer to Ch 5.5.3). Here you can view direction keys, speed, zoom, focus, iris, preset, tour, pan, scan, pattern, aux close, Figure 3- 1 and PTZ setup button.

  • Page 18: Scan

    Figure 3- 2 PTZ setting interface is shown as in Here you can set scan, preset, tour, pattern, assistant function and light and wiper plus view coordinate. Figure 3- 2 3.1 Scan Figure 3- 3 Scan interface is shown in Figure 3- 3 Steps to scan are: Step 1.

  • Page 19: Tour

    Figure 3- 4 Steps to preset are: Step 1. In preset box, input preset value. Step 2. Click on Go to, camera rotates to preset position. Step 3. Use direction key to rotate camera, and in preset box input preset value. Step 4.

  • Page 20: Pattern

    3.4 Pattern Pattern interface is shown in Figure 3- 6. Figure 3- 6 Steps to pattern are: Step 1. In pattern box input pattern value, click on Add. Step 2. Click on Start, to zoom, focus, iris or move. Step 3. Click on Stop to finish setup of one pattern. 3.5 Assistant Assistant interface is shown in Figure 3- 7.
  • Page 21 Figure 3- 8 Steps to light wiper are:  Click on Enable to enable light wiper function.  Click on Disable to disable light wiper function.

  • Page 22: Playback

    4 Playback Web client playback supports video playback and picture playback. Note: Before playback, user shall set storage management as in Ch 5.4. 4.1 Playback The playback interface is shown as in Figure 4- 1. Figure 4- 1 There are four sections: ...

  • Page 23: Playback File

    Figure 4- 2 Parameter Function When you see this button, it means pause or not played record. Click on this ① Play button, switch to normal play status. ② Stop Click this button to stop playing. Click on this button to go to next frame. ③...
  • Page 24 Figure 4- 3 Parameter Function Select “dav”, as video playback.  File Type Select “jpg” as picture playback.  Data Source Default is SD card. Step 1. Click on data in blue, time axis displays record file progress bar in color. While, green represents normal record, yellow represents motion detect record, red represents alarm record, and blue represents manual record.
  • Page 25 Figure 4- 5 Parameter Function It means records within searched start time and end time on the date. Search Record Download There are two formats: dav, mp4. Format...

  • Page 26: Playback Cut

    Parameter Function Record type is “dav”, click on download button to download file to local.  Record type is “mp4”, click on download button and download file to path in  Ch 5.1.2.5. Download Note: System does not support download and playback of MP4 file. Click on back button to go to calendar interface.

  • Page 27: Progress Bar

    4.1.5 Progress Bar Figure 4- 8 Parameter Function Click on it, means video in past 24 hours. 24 hours Click on it, means video in past 2 hours. 2 hours Click on it, means video in past 1 hour. 1 hour Click on it, means video in past 30 min.

  • Page 28: Play

    Playback file bar Snapshot type bar See Figure 4- 10. Figure 4- 10 4.2.1 Play Figure 4- 11 Default icon is and it means pause or not played picture. Click on play button to switch to normal play status. Icon become ...

  • Page 29: Playback File

    4.2.2 Playback File Figure 4- 12 Step 1. Click on file list , select snapshot file of the date. Step 2. Double click on file in list, to play this snapshot.
  • Page 30 Parameter Function It means all snapshot files within the start time and end time of selected date. Search Click on download button to download snapshot file to local. Download Click on back button to return to calendar interface and re-select time. Back Figure 4- 13...

  • Page 31: Snapshot Type

    4.2.3 Snapshot Type Figure 4- 14 Check snapshot file type, in file list only display file of selected type. See Figure 4- 14...

  • Page 32: Setup

    5 Setup Web client setup support camera, network, time, storage, system and system info view. 5.1 Camera 5.1.1 Conditions Here you can view device property information. Slight differences may be found due to different network Figure 5- 1 camera series. The setups become valid immediately after you set. See Note: Only motorized zoom lens device has zoom and focus function.
  • Page 33 Contrast It is to adjust monitor window contrast. The larger the number, the higher the contrast is. You can use this function when the whole video bright is OK but the contrast is not proper. Please note the video may become hazy if the value is too low. If this value is too high, the dark section may lack brightness while the bright section may over exposure .
  • Page 34 Note: Exposure Only when anti-flicker is outdoor, exposure mode is available.  Auto:  The video whole brightness can automatically change within the proper exposure range according to the different environments. The higher the gain max value is, the lower the noise is. ...
  • Page 35 It is to set the white balance mode. It has effect on the general White Balance hue of the video. This function is on by default. You can select the different scene mode such as auto, sunny, cloudy, home, office, night, disable and etc to adjust the video to the best quality.
  • Page 36 BLC Mode BLC is used for backlight situation.   Default BLC: auto exposure according to scene.  Custom: select area to exposure, the objective is to make appropriate brightness in selected area.   For the WDR scene, this function can lower the high bright section and enhance the brightness of the low bright section.
  • Page 37 Profile management has three modes: normal, full time and schedule. If you select normal, the video will Figure 5- 2 be configured as normal as in Figure 5- 2 If you select full time, you must select either day or night, and the video will be configured accordingly Figure 5- 3 Figure 5- 4 as in...

  • Page 38: Zoom And Focus

    Figure 5- 5 Important  The setup becomes immediately effective after you click on OK.  You can see WDR option only if your camera supports WDR function. System does not support long-time exposure or low noise mode. 5.1.2 Zoom and Focus Figure 5- 6 Parameter Function...

  • Page 39: Video

    Parameter Function Press minus key to make the focal plane of the lens move to Near close shot Press plus key to make the focal lens move to move to long Focus shot Speed Including 1，5，20，100 Restore all Restore all, the value of both zoom and focus are reset as 0 Adjust the focal plane of the lens to make the video image Auto Focus stay the clearest.
  • Page 40 Parameter Function There are three options: H.264(main profile standard, Encode mode H.264H (high profile standard), and MJPG encode.  The H.264, H.264H both are H264 bit stream. H.264 is the Main Profile encode and the You need to enable the sub stream function in your camera and set the resolution as CIF.
  • Page 41 Figure 5- 8 Please refer to the following sheet for detailed information. Parameter Function There are two modes: general (schedule) and Event Snapshot type (activation). Image size It is the same with the resolution of snapshot (main stream or sub stream). It is to set the image quality.
  • Page 42 Figure 5- 10 Figure 5- 11...
  • Page 43 Figure 5- 12 Figure 5- 13 Please refer to the following sheet for detailed information. Parameter Function  Here you can privacy mask the specified video in the Privacy mask monitor video.  System max supports 4 privacy mask zones. ...
  • Page 44  You can enable this function to overlay location information Location in video window.  You can click on setup button to set location information. You can use the mouse to drag location box to adjust its position. Alignment include align left and align right. ...

  • Page 45: Audio

    Figure 5- 14 5.1.3 Audio Please note some series devices do not support audio function. 5.1.3.1 Audio Figure 5- 15 The audio interface is shown as below. See Figure 5- 15 Please refer to the following sheet for detailed information. Parameter Function Sampling...

  • Page 46: Network

    Figure 5- 16 Figure 5- 17 Audio management currently supports PCM format to record and PCM, wav two forms to upload， and can select an audio file for the audio alarm linkage. The way to download the web alarm playback audio file into local is as follows: in the “choice”...

  • Page 47: Tcp/Ip

    5.2.1 TCP/IP Figure 5- The TCP/IP interface is shown as in . It supports IPv4 and IPv6. IPv4 supports static IP and DHCP. IPv6 supports static IP only. When user manually modify IP address, WEB will automatically jump to the new IP address. Figure 5- 18 Please refer to the following sheet for detailed information.

  • Page 48: Connection

    Preferred DNS DNS IP address. Alternate DNS Alternate DNS IP address. Enable You can use ARP/Ping command to modify or set the device IP ARP/Ping set address if you know the device MAC address. device IP Before the operation, please make sure the network camera address service.
  • Page 49 Figure 5- 19 Please refer to the following sheet for detailed information. Parameter Function It is the max Web connection for the same device. The value ranges from 1 connection to 20. Default connection amount is 10. TCP port Port range is 1025~65534. The default value is 37777. You can input the actual port number if necessary.

  • Page 50: Pppoe

    ONVIF 5.2.2.1 ONVIF（Open Network Video Interface Forum），this standard describes network video mode, interface, data type and data interaction mode. ONVIF Standard’s aim is to achieve a network video frame agreement and makes the network video products (including video front-end, video equipment, etc.) from different manufacturers completely compatible.

  • Page 51: Ddns

    Figure 5- 21 5.2.4 DDNS Figure 5- 2 The DDNS interface is shown as in The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
  • Page 52 Parameter Function Server Address DDNS server IP address Domain Name Your self-defined domain name. Username The user name you input to log in the server. Password The password you input to log in the server.  Device sends out alive signal to the server regularly. Default Update period is 10min.

  • Page 53: Ip Filter

    5.2.5 IP filter Figure 5- The IP filter interface is shown as in You can enable IP filter function so that some specified IP/MAC user can access the network camera. You can add IP address or IP address section. If you do not check the box here, it means there is on access limit. Here you can add IP address and MAC address.

  • Page 54: Upnp

    Figure 5- 25 Please refer to the following sheet for detailed information. Parameter Function Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. For the server supports the anonymity function. You can auto Anonymity login anonymously.

  • Page 55: Snmp

    In the Windows OS, From Start->Control Panel->Add or remove programs. Click the “Add/Remove Windows Components” and then select the “Network Services” from the Windows Components Wizard. Click the Details button and then check the “Internet Gateway Device Discovery and Control client” and “UPnP User Interface”.
  • Page 56 Figure 5- 27 Please refer to the following sheet for detailed information. Parameter Function  SNMP Version Check SNMP v1, device only process v1 info.  Check SNMP v2, device only process v2 info.  Check SNMP v3, can set username, password and encryption method.
  • Page 57 Figure 5- 28 Check SNMP v3 version and SNMP port, read community, write community, Trap address, Trap port are same with SNMP v1 and SNMP v2 versions. Only when SNMP version is SNMP v3, user need to configure parameter in chart. Parameter Function SNMP Version...

  • Page 58: Bonjour

    Parameter Function Encryption Password not less than 8 characters. Password 5.2.9 Bonjour Figure 5- The Bonjour interface is shown as below. See Bonjour is based on the multicast DNS service from the Apple. The Bonjour device can automatically broadcast its service information and listen to the service information from other device. You can use the browse of the Bonjour service in the same LAN to search the network camera device and then access if you do not know the network camera information such as IP address.
  • Page 59 Figure 5- 30 Please refer to the following sheet for detailed information. Parameter Function Select to enable multicast function. Main stream and sub stream cannot be Enable used at the same time. Multicast address Main/sub stream multicast default address is 224.1.2.4 and its range is 224.0.0.0～239.255.255.255.
  • Page 60 Figure 5- 31 WIFI setting method is as follows: ，show as ，means enabling WIFI function. Step 1 Click Step 2 Click “wireless network ID search”，and shows the wireless network hot spot of the current network camera environment in the list. Figure 5- 32...
  • Page 61 Click “add a wireless network ID” when need to add a wireless network manually，pop out Step 3 an interface in the figure below, and enter network ID in the dialog box. Figure 5- 33 Step 4 Click “wireless network ID search”，if can search the wireless network hot spot, it means the network ID is available.

  • Page 62: 802.1X

    5.2.11 802.1x 802.1x (port based network access control protocol) supports manual selection of authentication method to control if device connected to LAN can join the LAN. It well supports authentication, charging, safety and management requirement of network. Figure 5- 35 Please refer to the following sheet for detailed information.

  • Page 63: Event

    bandwidth of the each queue. Level 0 is the lowest, and level 63 is the highest. It can also discard at the different ratio when the broad bandwidth is jam. Figure 5- 36 Please refer to the following sheet for detailed information. Parameter Function Real-time...
  • Page 64 Figure 5- 37 Figure 5- 38...
  • Page 65 Figure 5- 39 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Here you can set arm/disarm period. Click on set button to open period Working setup menu.
  • Page 66 Parameter Function Check it and so when alarm occurs, system will auto record. You shall set Record record period in Storage>Schedule and select auto record in record control interface. System can delay the record for specified time after alarm ended. The value Record Delay ranges from 10s to 300s.

  • Page 67: Alarm

    Different colors represent different areas. Each area can set different detection zones. Detection zone cam be irregular and discontinuous. If device monitoring zone is large, user can sub-divide the area into several zones for better motion detect. Please refer to the following sheet for detailed information. Parameter Function Default area name includes Region0, Region1, Region2,...
  • Page 68 Figure 5- 41 Please refer to the following sheet for detailed information. Parameter Function Enable After enabled, relay activation will work. Check it and enable the PIR alarm.  This function becomes activated in the specified periods. Working  There are six periods in one day. Please draw a circle to period enable corresponding period.
  • Page 69 5.3.2.1 Alarm Linkage Figure 5-42 Parameter Function Enable Check it and enable the alarm linkage. Relay-in The default alarm 1，some products can choose alarm 2. Two types of sensor which are normally open (NO) and normally closed (NC), switch from normally open to normally closed, open the alarm. Switch from normally Sensor Type closed to normally open, shut the alarm.

  • Page 70: Abnormity

    Parameter Function ON/OFF ON means flash is on; OFF means flash is off. Weak-strong Via dragging this bar to adjust flash brightness. Check and it means the day flash works. Period Period that flash is on. 5.3.2.3 Audio detection Figure 5-44 parameter Function Enable...
  • Page 71 Figure 5- Device without SD card function does not have the above three statuses. See Figure 5- 45 Figure 5-46 Figure 5-47 Please refer to the following sheet for detailed information.
  • Page 72 Parameter Function Check to alarm when SD card is abnormal. Enable Check to enable relay-out alarm. Relay-out Relay out The alarm output can delay for the specified time after alarm stops. The delay value ranges from 10s to 300s. Note: No SD card, capacity warning, SD card error, relay-out delay all start from alarm occurs.

  • Page 73: Storage Management

    Figure 5- 49 5.4 Storage Management 5.4.1 Schedule Before schedule setup, user must set record mode is auto or manual. Note: If record mode in record control is off, then device will not snapshot according to schedule. 5.4.1.1 Record Schedule Record schedule steps: Step 1.
  • Page 74 Note: Period setup can be done by dragging in record schedule interface while not releasing left mouse. Figure 5- 51 Figure 5- Step 3. Click on OK, return to record schedule interface. See  Green color stands for the general record/snapshot. ...
  • Page 75 Figure 5- 53 Figure 5- Step 2. From Monday to Sunday select snapshot time, click on setup on the right. See  Set snapshot period according to actual need. There are six periods available each day.  By checking or unchecking, user can add or delete three types of snapshot schedule: General, Motion and Alarm.
  • Page 76  Yellow color stands for the motion detect record/snapshot.  Red color stands for the alarm record/snapshot. Figure 5- 55 Step 5. In snapshot interface, click on OK. System prompts it is successfully saved. 5.4.1.3 Holiday Schedule Holiday schedule can set specific date as holiday. Figure 5- Step 1.

  • Page 77: Destination

    Step 3. Check Record/Snopshot, click on Save. System prompts it is successfully saved. Step 4. Check Record Schedule/Snapshot Schedule interface, click on setup next to Holiday, refer to setup of Monday to Sunday. Step 5. Complete setup of holiday, then it records/snapshots according to date in holiday schedule. 5.4.2 Destination 5.4.2.1 Path Figure 5-...
  • Page 78 Figure 5- 58 5.4.2.3 FTP Figure 5- The FTP interface is shown as in You need to check the box to enable the FTP function. When network disconnect occurred or there is malfunction. Emergency storage can save the record/snapshot picture to the local SD card. Figure 5- 59 5.4.2.4 NAS You need to check the box to enable the NAS function.

  • Page 79: Record Control

    Figure 5- 60 Parameter Function Server Address Set IP address of NAS server. Remote Set storage directory, videos and pictures can be stored in to corresponding server Directory directory. 5.4.3 Record control Figure 5- The record control interface is shown as in Figure 5- 61 Please refer to the following sheet for detailed information.

  • Page 80: System

    Pre-record Please input pre-record value here. For example, system can record the four seconds video in the buffer. The record begins from the fifth second. Note: Configure pre-record time, when alarm or motion detection occurs, if there is no record, system will record the preceding n seconds record.
  • Page 81 Video This is to display video standard such as PAL. Standard Language You can select the language from the dropdown list. Figure 5- The date and time interface is shown as in Figure 5- 63 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list.

  • Page 82: Account

    You can set the time server address. NTP server It is to set the time server port. Port It is to set the sync periods between the device and the time server. Update period 5.5.2 Account  For the character in the following user name or the user group name, system max supports 15- digits.
  • Page 83 Enable anonymity login: Enable anonymity login, and input IP. No username or password is required, you can log in by anonymity (with limited rights). You can click logout to end your session. Figure 5- Add user: It is to add a name to group and set the user rights. See There are four default users: admin/888888/666666 and hidden user “default”.
  • Page 84 Figure 5- 66 5.5.2.2 Group The group management interface can add/remove group, modify group password and etc. Figure 5- The interface is shown as in...
  • Page 85 Figure 5- 67 Figure 5- Add group: It is to add group and set its corresponding rights. See Please input the group name and then check the box to select the corresponding rights. It includes: preview, playback, record control, PTZ control and etc. Figure 5- 68 Modify group Figure 5-...

  • Page 86: Ptz

    5.5.3 PTZ Please note only some series products support this function. Figure 5- The PTZ interface is shown as in Figure 5- 70 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Set corresponding dome address.

  • Page 87: Import/Export

    Figure 5- 71 5.5.5 Import/Export Figure 5- The interface is shown as in Figure 5-72 Please refer to the following sheet for detailed information. Parameter Function It is to import the local setup files to the system. Import It is to export the corresponding system setup to your local PC. Export 5.5.6 Remote control Note:...

  • Page 88: Auto Maintenance

    Figure 5-73 Parameter Function Learn Bind remote control or wireless alarm with equipment. Clear Unbind remote control with equipment. Start arm after the time you choose, disarm comes into effect immediately. Note: Arm/Disarm With disarm status, all the following alarms won’t trigger: motion detect alarm, masking alarm, local alarm, PIR alarm, wireless alarm.

  • Page 89: Upgrade

    Parameter Function Auto Reboot Check it and set auto reboot time. Auto Delete Old Check it and set period within 1~31 days. Files 5.5.7 Upgrade Figure 5- The upgrade interface is shown as in Please select the upgrade file (file extension is “.bin”) and then click the update button to begin firmware update.

  • Page 90: Log

    Figure 5- 76 5.6.2 Log Figure 5- Here you can view system log. See Figure 5- 77 Please refer to the following sheet for log parameter information. Parameter Function Set the start time of the requested log. (The earliest time is 2000/1/1) Start time Set the end time of the requested log.
  • Page 91 Figure 5- The online user interface is shown as in Here you can view current online user, group name, IP address and login time. Figure 5- 78...

  • Page 92: Alarm

    6 Alarm Please note some series product does not support this function. Figure 6- 1 Click alarm function, you can see an interface is shown as in Here you can set device alarm type and alarm sound setup. Figure 6- 1 Please refer to the following sheet for detailed information.
  • Page 93 Type Parameter Function Alarm Audio When alarm occurs, system auto generates alarm audio audio. The audio supports customized setup. Path Here you can specify alarm sound file.

  • Page 94: Log Out

    7 Log out Figure 7- 1 Click log out button, system goes back to log in interface. See Figure 7- 1 Note:  This manual is for reference only. Slight difference may be found in user interface.  All the designs and software here are subject to change without prior written notice. ...
