ECL-IP3D50
User's Manual
Version 4.2.0

Advertisement

Table of Contents
loading

Summary of Contents for Eclipse Security ECL-IP3D50

  • Page 1 ECL-IP3D50 User’s Manual Version 4.2.0...
  • Page 2 Welcome Thank you for purchasing our Network camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
  • Page 3: Important Safeguards And Warnings

    Important Safeguards and Warnings 1.Electrical safety All installation and operation here should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 4 Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device.
  • Page 5: Table Of Contents

    Table of Contents General Introduction ......................1 Overview ........................1 Features ........................1 Specifications ......................2 Structure ..........................7 Components ......................7 Framework and Dimension ..................7 Device Installation ......................... 9 Installation Steps ...................... 9 Restore Factory Default Setup Introduction ............11 Quick Configuration Tool ....................
  • Page 6: General Introduction

    1 General Introduction 1.1 Overview This series network camera integrates the traditional camera and network video technology. It adopts video data collection, transmission together. It can connect to the network directly without any auxiliary device. This series network camera uses standard H.264 video compression technology, which maximally guarantees the video quality.
  • Page 7: Specifications

    1.3 Specifications Please refer to the following sheet for network camera performance specification. Model Parameter Main Processor TI Davinci high performance DSP Embedded LINUX System Support real-time network, local record, and remote operation at the Resources same time. User Interface Remote operation interface such as WEB, DSS, PSS System Status Bit stream statistics, log, and software version.
  • Page 8 Wire Network 1-ch 10/100 M Ethernet , RJ45 port HTTP, TCP/IP, ARP, RTSP, RTP,UDP, RTCP, SMTP, FTP, DHCP, Network Protocol DNS, DDNS, PPPOE, IPv4/6, SNMP, UPNP, NTP Remote Monitor, system setup, file download, log information, maintenance , Operation upgrade and etc Restore Default Built-in Reset button Setup...
  • Page 9 ≤95% Humidify Φ 113×86 Dimensions(mm) Weight 280g (Excluding box) Installation Ceiling and wall mount Model ECL-IP3D50 Parameter Main Processor High performance DSP Embedded LINUX System Support real-time network, local record, and remote operation at the Resources same time. User Interface...
  • Page 10 Image Sensor 1/3-inch CMOS 1/2.8-inch CMOS 1/3-inch CMOS Pixel 1280(H)*960(V) 1920(H)*1080(V) 2048(H)*1536(V) Day/night Support day/night mode switch Gain Control Fixed/Auto White Balance Manual/Auto On/Off Manual/Low noise/Low motion blur/Auto Exposure Mode It ranges from 1/3 to 1/10000 Video H.264/H.264H/MJPEG Compression Note: Some versions do not support H.264H. Standard PAL: Main stream...
  • Page 11 Operation upgrade and etc Restore Default Built-in Reset button Setup IR light IR light 10~ 20M. Power DC12V power and PoE. Warning! Do not connect these two power supplying sources to the device at the same time; it may result in device damage! Power DC 12V DC 12V...
  • Page 12: Structure

    2 Structure 2.1 Components You can refer to the following figure for multiple-function combination cable information. See Figure Figure 2-1 Multiple-function combination cable Please refer to the following sheet for detailed information. Component Component Name Component 1 Device lens Component 2 Dome body Component 3 Dome enclosure...
  • Page 13 Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and Figure 2-3. Figure 2-2 Dimension illustration 1 Figure 2-3 Dimension illustration 2...
  • Page 14: Device Installation

    3 Device Installation 3.1 Installation Steps Important Before the installation, please make sure the installation environments can at least support 3x weight of the camera. Please follow the steps listed below to install the device. Please refer to Figure 3-1 for reference. Step 1 Turn clockwise to remove the decoration ring from the snap joints.
  • Page 15 Figure 3-2 Device installation illustration 2 Note This series product supports two cable exits. One is from the bottom and the other is from the side. Please refer to the following figure for cable exit from the side information. Figure 3-3 Device installation illustration 3 Please earth the GND port of the device to enhance the device reliability.
  • Page 16: Restore Factory Default Setup Introduction

    Figure 3-4 Device installation illustration 4 3.2 Restore Factory Default Setup Introduction Important Please use RESET button when device is running. Step1 Please refer to step1 and step2 in chapter 3.1to loose the dome body. Push a little bit; you can take the dome body from the gland cover.
  • Page 17: Quick Configuration Tool

    4 Quick Configuration Tool 4.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 4.2 Operation Double click the “ConfigTools.exe”...
  • Page 18 In the configuration tool search interface (Figure 4-1), please select a device IP address and then double click it to open the login interface. Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-3. In Figure 4-3, you can view device IP address, user name, password and port.
  • Page 19: Web Operation

    5 Web Operation This series network camera products support the Web access and management via PC. Web includes several modules: Monitor channel preview, system configuration, alarm and etc. 5.1 Network Connection Please follow the steps listed below for network connection. ...
  • Page 20 Figure 5- 2 Web login After you successfully logged in, please install WEB plug-in unit. Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction. See Figure 5- 3. Figure 5- 3 Web monitoring window...
  • Page 21: Faq

    6 FAQ I can not boot up Please click RESET button for at least five seconds to restore factory default setup. the device or operate properly. The water leakage The unauthorized front or rear cap remove many result in water occurred.
  • Page 22: Appendix Toxic Or Hazardous Materials Or Elements

    Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component ○ ○ ○ ○ ○ ○ Device Case ○ ○ ○ ○ ○ ○...
