Location
Overlay
Refresh
5.1.2.4 Path
The storage path interface is shown as in Figure 5- 14.
Here you can set snap image saved path and the record storage path.

The default monitor image path is C:\Documents and
Settings\Administrator\WebDownload\Snapshot.

The default monitor record path is C:\Documents and
Settings\Administrator\WebDownload\LiveRecord.

The default playback snapshot path is C:\Documents and
Settings\Administrator\WebDownload\PlaybackSnapshot.

The default playback download path is C:\Documents and
Settings\Administrator\WebDownload\PlaybackRecord.

The default playback cut path is: C:\Documents and
Settings\Administrator\WebDownload\VideoClips.
Note:
Administrator is locally logged in PC account.
Please click the Save button to save current setup.

You can enable this function to overlay location information
in video window.

You can click on setup button to set location information.
You can use the mouse to drag location box to adjust its
position. Alignment include align left and align right.

You can enable this function to display overlay picture.
Click on disable to turn it off.

Click on Upload Picture to overlay local picture into
monitoring window. You can drag the yellow box to move
it.
Note:
You cannot enable location and overlay at the same time.

Set privacy mask, channel title, time title, location, overlay
and save the change. You can click on Refresh to see
effect.
40
