Eclipse Security ECL-IP3D50MV Manual page 59

Please refer to the following sheet for detailed information.
Parameter
Enable
Multicast address
Port
5.2.12 WIFI
Note:
Some series devices don't support WIFI and WPS function.
WIFI
WIFI work information column can show the name, status, IP information of the Current Hot Spot.
Usually please "refresh" WIFI work information after reconnection to ensure the real-time display of the
work status, because it often takes some time to connect WIFI Hot Spot, which depends on the network
signal strength.
Function
Select to enable multicast function. Main stream and sub stream cannot be
used at the same time.
Main/sub stream multicast default address is 224.1.2.4 and its range is
224.0.0.0～239.255.255.255.
Multicast port. Main stream is 40000, sub stream is 40002 and the range is
1025～65534.
Figure 5- 30
55
