5. Door Preparation

5.1 Prepare the Door:
a. Clean the guides if there is any oil or wax present using a suitable white spirit. The only lubricant suitable for use on
door guides is silicon spray. DO NOT use WD-40, RP-7, petroleum grease, or similar.
b. Remove the locking bars or disable the lock.
c. Install the locking bar covers
in the holes while the door operates
d. Affix the supplied warning labels where they are clearly visible on the inside of the door.
e. Install the collar kit
4
f. Fit the collar kit hard up against the drum.

6. Fit the Weight Bar

If the door has a handle a weight bar must be fitted to ensure the door doesn't balloon during operation:
a. Remove the door handle
b. Fit the weight bar
5
Washer and the two (2) M4 Nilock Hex nut
7
If the door does not have a handle:
a. Locate the centre of the door at the bottom rail.
b. Place the weight bar at this point and mark the two positions where the fasteners will go
c. Drill the two 4.5mm holes in the door and fit the weight bar
and the two (2) Flat Washer
d. Check that the door is still balanced and smooth. If not, then the door may require servicing.
8
WITH HANDLE
®
installation instructions
if there are locking bar holes in the guides. This ensures fingers cannot be placed
2
to the OPPOSITE end to where the opener is being installed.
2
and refit the handle using the two (2) M4x50mm Pan Head Screw
and the two (2) M4 Nilock Hex nut
7
5
6
7
.
6
using the two (2) M4x50mm Pan Head Screw
5
.
6
5
8
7
WITHOUT HANDLE
and the two (2) Flat
8
WARNING! To reduce
the risk of damage to
persons or property,
6
be sure to cut off any
excess thread of the
screw that protrudes
the weight bottle and
file any burs.
