B&D Roll-A-Door R1D Installation Instructions Manual

Auto-Lock Contents

GARAGE DOOR LOCK - ORDER NO. 87835
ITEM DESCRIPTION
1 GARAGE DOOR LOCK
2 BUTTON HEAD SCREW ZN M6 X 10
3 TAPTITE "P" BLACK SCREW M3 X 14
4 BATTERY C-LR14
5 WIRELESS BASESTATION MODULE
6 VELCRO
WARNING! This lock has been designed
to work with B&D Roll-A-Door garage
doors.
If you fit this lock to other branded garage door, we
cannot guarantee the performance of the lock and
any performance warranties will not apply. This is
subject to any Statutory Guarantees that may apply.
Please refer to our warranty terms and conditions
set out in the B&D Owners Opener Handbook.
This device will slide a bolt into the guide
track automatically when the door is
closed. DO NOT install in garages that
have only one exit.
For emergency lock / unlock press the lock / unlock
button on the Auto-Lock. This will disengage the lock
from the guide track and allow you to disengage the
opener and open the door. The lock will automatically
re-engage after the next complete cycle.

Important Safety Instructions

WARNING!
CAUTION:
Burns
Muscle strain
Doc # 161071_00
Released 12/11/21
Auto-Lock Kit
For B&D Roll-A-Door
QTY
2
4
8
4
1
1
• DO NOT attempt to disassemble, repair or modify the product.
This will invalidate the warranty.
• DO NOT allow children to play with the Auto-Lock.
• DO NOT install in garages that have only one exit.
• DO NOT cover, paint or lubricate the product.
• DO NOT handle damaged or leaking batteries
• The Auto-Lock Kit contains sealed lead-acid batteries that must be disposed of
properly at the end of their useful life.
• DO NOT attempt to lift the door manually when the Auto-lock is engaged.
These instructions are intended for professional garage door installers.
B&D encourages recycling of packaging as is reduces waste to landfill
and achieves environmental benefits.
R1D.
®
Bracket Kit
(Kit sold separately)
STANDARD BRACKET KIT - ORDER #MC0123
ITEM DESCRIPTION:
7 LOCK STRIKER
8 WALL BRACKET
9 CORRUGATED PLATE
10 ALCOHOL WIPES
LIMITED SIDEROOM BRACKET KIT - ORDER #MC0115
ITEM DESCRIPTION:
7 LOCK STRIKER
8 WALL BRACKET
9 CORRUGATED PLATE
10 ALCOHOL WIPES
11 60mm HEAD STOP
WARNING! Ensure the opener is not engaged
when the Auto-lock is being used with only
the bolt unit. Failure to do so may void the
Warranty of the opener.
Auto-Lock compatible with RDO-1V4
openers with firmware #59
CAUTION:
Ensure bolt on Auto-lock is free to
move during limit setup.
It is our strong recommendation that
your opener be fitted with SAFETY BEAMS.
Safety Beams detect any obstructions in the door/
gate's path and override automatic operation
if one presents. These must be installed as in
accordance with AS/NZS 60335-2-95:2012.
QTY
2
2
1
2
QTY
2
2
1
2
1
