- Page 1 ® Controll-A-Door P Diamond Sectional Door Opener SDO-2v2 Instruction Manual Technical Document Installation Manual 1.01 04 June 2012 English N1854 Part # 79073 (Manual) B&D Doors is a division of B&D Australia Pty Ltd ABN 25 010 473 971 www.bnd.com.au...
-
Page 2: Table Of Contents
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual ® Controll-A-Door P Diamond Sectional Door Opener SDO-2v2 Battery Back Up Installation Safety Rules How To Use Your Opener Risk Assessment Transmitter Default Settings & Specifi cations Transmitter Battery About Your Opener Locking Operating Controls Manual Release Kit Contents... -
Page 3: Safety Rules
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Safety Rules Please read these important safety rules These safety alert symbols indicate a personal safety or property damage instruction exists. READ THESE INSTRUCTIONS CAREFULLY. This automatic garage door opener is designed and tested to offer safe service provided it is installed and operated in strict accordance with the following safety rules. -
Page 4: Risk Assessment
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Risk Assessment Please refer to the risk assessment table below and ensure all the necessary controls are in place. Installation Risk Assessment Hazard Control Muscular strain from incorrect lifting • Practice correct lifting techniques (carton weighs 9 kg) of opener Muscular strain from incorrect lifting •... -
Page 5: Default Settings & Specifi Cations
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Default Settings & Specifi cations Factory default settings Default Step Minimum Maximum Maximum opener run time 60 seconds Courtesy light time 4 minutes (approx.) Obstruction force margin Auto-Close time 30 seconds Technical specifi cations Power supply 230V - 240Va.c. -
Page 6: About Your Opener
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual About Your B&D Opener Thank you for choosing a Controll-A-Door® P Diamond Soft Start/Soft Stop automatic garage door opener, designed and developed in The opener eases into and out of each cycle making Australia by B&D Doors. -
Page 7: Operating Controls
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Operating Controls Terminal Block. V+ is used to power devices such as Wireless Safety Beam, external receiver etc. EB1 input is used to connect to Safety Beam. 0V (Input) is a 0 volt connection for Safety Beam, external receiver, osc, aux etc. EB2 input is used to connect to second Safety Beam.. - Page 8 ® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Fig. 01...
-
Page 9: Kit Contents
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Kit Contents Powerhead Unit (Fig. 02) 1 x Controll-A-Door P Diamond powerhead ® 1 x Transmitter pack (Pack includes two keyring transmitters and batteries) 1 x Wall mount transmitter with battery 2 x Door attachment arms Fig. -
Page 10: Installation
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual C-Rail Assembly Step 1 - Attach C-Rail to Powerhead Locate and insert the powerhead’s shaft into the C-Rail’s Shaft sprocket as shown in (Fig. 05). Fig. 05 Locate shaft into sprocket Step 2 - Secure C-Rail to Powerhead Fix the two track brackets as shown in (Fig. -
Page 11: Determine Door Type
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Determine the Door Type Step 3 - Determine the Door Type Proceed from Step 5 Determine which type of garage door you have as illustrated (Fig. 07) (Fig. 09). For a sectional (panel) door on tracks (Fig. -
Page 12: Mounting - Track Type Door
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Mounting on a Track Type Door Step 4 - Determine Bracket Position Open the door and fi nd the highest point of travel of Level the top door panel. Level Using a level, transfer this height to the wall above the Track door (Fig. -
Page 13: Mounting - Non-Track Type Door
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Mounting on a Non-Track Type Door Centre of door WARNING: Make sure concrete, brick wall or timber lintels are solid and sound so as to form a secure mounting platform. Fig. 14 Step 8 - Determine the Door’s Centre Find the centre of the door and mark this location both above the door and on top of the door. -
Page 14: Mounting Door Bracket & Arms
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Mounting Door Bracket and Arms Step 11.1 - Alternative Mounting Option Drill hole at centre of track The opener can be fastened to the roof by driving a bolt (recommended bolt size through the C-Rail into a structural timber support. The bolt M6 or M8) (Fig. -
Page 15: Programming The Opener
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Setting Speed and Limits Step 14 - Setting Speed Mode The default speed of the opener has been set to suit the majority of applications. However, there are 3 speed modes available if required:- Slow - to suit one piece door without tracks Medium ( default ) - suits majority of applications Fig. - Page 16 ® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Setting Travel Limits IMPORTANT NOTE: The OPERATE button will not function until the open and close limit positions are set. NOTE: The door and shuttle must be engaged into the chain index. The door should be open Fig.
-
Page 17: Testing Safety Obstruction Force
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Testing Safety Obstruction Force CAUTION: Take care when testing the safety obstruction force. Failure to follow this warning can result in serious personal injury and/or property damage. 16.1 Test the Close Cycle Press the OPERATE button to open the door (Fig. -
Page 18: Coding Transmitters
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Coding Transmitters Step 17.1 - Storing the Transmitter Code The opener can only operate from transmitters that have been programmed into its receiver. The receiver needs to learn the codes of any transmitter that will be used with the operator. -
Page 19: Vacation Mode
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Coding Transmitters Step 17.3 - Setting the Transmitter to Operate Vacation Mode The opener can be programmed into a “Vacation Mode” where the opener will not respond to any transmitter except one preprogrammed unit. Press CODE SET button three times. -
Page 20: Pet (Pedestrian) Mode
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Coding Transmitters Step 17.5 - Setting the Transmitter to Operate Pet (Pedestrian) Mode The opener can be programmed into a “Pet Mode” where the door opens partially to allow pets to enter/exit the garage: Press the CODE SET button fi... -
Page 21: Wireless Safety Beam Installation
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Wireless Safety Beams Installation WARNING: Safety beams must be installed if the closing force at the bottom edge of the door exceeds 400N (40kg force). This is in compliance with AS/NZS 60335-2-95 Step 20.1 -Wireless Photo Electric (PE) Beams Fig. - Page 22 ® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Wireless Safety Beams Installation Step 20.3 -Connecting The Base Station To The Opener Connect WHITE wire from base station to 0V on the terminal block of the opener Connect RED wire from base station to V+ on the terminal block of the opener.
- Page 23 ® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Wireless Safety Beams Installation Step 20.5 -Fixing The Base Station To Wall/ Opener The base station can be attached directly to a sectional opener using the M8 bolt and nut supplied. The wire can be fed through the top gromet of the opener (Fig.
-
Page 24: Wired Safety Beam Installation
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Wired Safety Beams Installation WARNING: Safety beams must be installed if the closing force at the bottom edge of the door exceeds 400N (40kg force). This is in compliance with AS/NZS 60335-2-95 Step 19 - Safety Beams (optional) Fig. -
Page 25: Accessories
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Accessories Terminal Block A variety of wired accessory items can be connected to the terminal block such as Safety Beams, electric key switch, (Fig. 47). and more Terminal connections from top down are as follows: EB1 (Safety Beam input) 0V (0V for Safety Beam) EB2 (Safety Beam input) -
Page 26: Battery Back Up Installation
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Battery Back Up Installation Fig. 48 Battery Back Up (optional) 7. Connect item 5 and 10 together (Fig 48). The opener has provision for a Battery Back Up kit 8. Reconnect power. that allows continued operation of the door in the Testing Battery Back Up absence of mains power. -
Page 27: How To Use Your Opener
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual How to use your opener For maximum effi ciency of your opener, your garage door must be in good operating condition. An annual service of your garage door by an Approved Dealer is recommended. CAUTION - Activate the opener only when Fig. -
Page 28: Transmitter Battery
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual How To Use Your Opener Removing the Battery From the Transmitter (Battery Type: 3V Lithium Battery CR2032). Use a non-metallic object (e.g. pen) to remove the battery. (Fig. 50) Inbuilt Locking Facility Fig. 50 DO NOT lock your door when your opener is engaged as it has inbuilt locking facility. -
Page 29: Safety Beam
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual How To Use Your Opener Safety Beam Vacation Mode A Safety Beam Kit (Part No 062734) may be fi tted to this The radio receiver of the garage door opener can be opener. turned off to all but one transmitter via Vacation Mode. -
Page 30: Maintenance
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Maintenance Maintenance Yearly Whilst your opener does not require any periodic B&D suggests that you contact your nearest Approved maintenance, the door that it is fi tted to, does. Your Dealer to perform an annual door service. garage door is a large, heavy, moving object and should be tested regularly to ensure it is in good condition. -
Page 31: Troubleshooting Guide
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Troubleshooting Guide Symptom Possible cause Remedy The opener does not work from the Garage door in poor condition e.g. Check the door’s operation - see transmitter springs may be broken monthly maintenance (Page 30) The opener does not have power Plug a device e.g. -
Page 32: Parameters
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Parameters Door status indicators Door opener state OPEN LED (green) CLOSE LED (red) Beeper Open Close Opening Flashing Closing Flashing Door travel stopped Flashing Flashing Door obstructed when opening Flashing Door obstructed when closing Flashing Beeps while door is moving... -
Page 33: Parts List
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Spare Parts List © Copyright 2012 B&D Doors Diamond PD Power Drive : Instruction Manual... -
Page 34: Warranty
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Warranty Product: CAD P Purchased from:______________________________Purchaser:___________________________________ (described as “you” below) Address:_____________________________________Installed by:__________________________________ Installed on (date):____________________________Invoice No:__________________________________ Making a claim - To make a warranty claim you must: produce a copy of the receipt of purchase, together with this warranty certifi cate with the above details completed;... - Page 35 ® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Warranty instructions - failure to observe any instructions or directions (including “warning” notifi cations in the Instruction Manual), provided with the Product or given to you; other devices - the Product being fi tted to any door or other closing device which is not of the type or condition defi...
-
Page 36: Optional Accessories
® Controll-A-Door P Diamond SDO-2v2 Instruction Manual Optional Accessories There is a range of additional accessories for your added convenience and security. • Safety Beams - Part No 062734. Gives additional protection if the door is closing onto your property or person. Simply breaking the beam “stops”... - Page 38 QLD Offi ce: 17 Oasis Court, Clontarf 4019. Ph: (07) 3883 0200 NSW Offi ce: 34-36 Marigold St, Revesby 2212. Ph: (02) 9722 5555 VIC/TAS Offi ce: 147-153 Canterbury Road, Kilsyth 3137. Ph: (03) 9237 7766 SA Offi ce: 23 Frederick Road, Royal Park 5014. Ph: (08) 8440 4747 WA Offi...
