RASFinder MTASR3-200 Quick Start Guide
Address of the remote user in dotted-decimal notation format.
Protocol - If you select Protocol as the filter type, the Add/
Edit Filters dialog box is displayed with Protocol and Port
drop-down lists active. Select either TCP or UDP from the
Protocol drop-down list and select either Telnet, FTP, or SFTP
from the Port drop-down list.
Domain Name - If you select Domain Name as the filter type,
the Add/Edit Filters dialog box is displayed with an active
Domain Name field. Enter the domain name consisting of a
sequence of names separated by periods (dots) followed by an
entension; e.g., "pictures.computers.com". The domain name
can be up to 39 alphanumeric characters including periods.
Note: Current filter entries are displayed in the Existing Entries
window.
Click OK to add the remote user to the Filters List dialog box
and then click OK again to return to the User List dialog box.
11. Click Add User to continue adding users to your database.
12. After adding all current users to the database, click Down-
Load to write the user database to the RASFinder.
24
