Install the Shipping Bracket
8. Using your fingers, raise the robotic elevator using the two cutout holes
Do not raise the robotic elevator higher than the top of the chassis to avoid
Important
disengaging the elevator from the track.
9. While holding the robotic elevator at the top of the chassis, install the
10. Using a #1 Phillips screwdriver, remove the two screws under the
11. Once the bracket is in place, release the elevator and allow it to rest on
December 2022
on both sides of the robot until it is level with the top of the library
chassis. It takes approximately ten to 15 seconds to raise the robotic
elevator fully.
Figure 6 Use the cutout holes to raise the robotic elevator.
robotic shipping bracket in the slot 5 drive bay (see Figure 2 on page 6).
Note: It may be helpful to have a second person install the bracket
while you hold the elevator in place.
handle of the robotic shipping bracket (1) and install the two screws at
the ends of the shipping bracket to secure it to the chassis (2).
Figure 7 The robotics shipping bracket rear panel.
the robotic shipping bracket.
