Universal Space FUNFAIR BASH Operation Manual page 19

Rev. 1.0
9.1.3 Monitor Assy.
No. Part No.
1 F126-129-000
2 F126-131-000
3 F126-132-000
4 F126-133-000
5 F126-134-000
6 F126-135-000
7 F126-411-000
8 F126-407-000
9 F126-130-000
10 F126-101-000
11 F126-122-000
12 F126-197-000
13 F126-184-000
18
K3 code
20211211027 Monitor down fixed plate
20611211004
20611211005
20611211020
20611211021 Touch screen long sticker
20611211023 Touch screen short sticker
21202046001 46" sensor touch screen
21201047001
20211211028 Monitor up fixed plate
20211211001 Monitor fixed plate
20211211020 Monitor down cant board
20101020040 countersunk head set
20101010043 countersunk head set
Name
Long sticker
Short sticker
Monitor glass
47" LCD
Cross recessed
screw
Cross recessed
screw
Spec.
t2 powder black
t3 single with tape
t3 single with tape
t5
t10 double with tape
t10 double with tape
F46WHOOU-02
MT47W-2630
t2 powder black
t2
t2
M4×8 color zinc
M5×20 black
Qty
1
2
2
1
2
2
1
1
1
2
1
6
7
