9. OVERALL CONSTRUCTION

9.1 Mechanical Part
9.1.1 Castor, T-molding, coin door assy.
No. Part No.
1 F126-124-000 20211211022
2 F126-171-000 26000008000
3 F126-125-000 20211211023
4 F126-172-000 26000010000
5 F126-446-000 25501000056
6 F126-449-000 26000015000
7 F126-200-000 20101040007
8 F126-215-000 20102000014
9 F126-221-000 20104000021
10 F126-186-000 20104010036
11 F126-205-000 20102100030
16
Code No.
Cabinet front T-molding
2.5" leveler
Cabinet side T-molding
2.5" castor bracket
Hexagon socket button head
Hexagon nut
Cross recessed hexagon bolt
with indentation
Cup head square neck bolts
Hexagon nut with flange
Name
2.5" castor
Coin door
screws
Material/Spec. Qty
t1.2 powder red 2
M16X100
4
(zinc plating)
t1.2 powder red 2
δ3(zinc plating) 4
3-2689-52 4
Assembly
1
(powder black)
M4×20 nickel
14
plating
M16 4
M6×25
32
GB/T29.2-1988
M5×25 black 8
M5 8
