User Authentication
Authentication Type
Select the desired user Authentication Type and click the Save button:
•
Local –
•
RADIUS –
authentication.
Local or RADIUS
Local Authentication Input
RADIUS Authentication Input
Multi-Tech Systems, Inc. RouteFinder SOHO RF820/RF820-AP & RF830/RF830-AP User Guide (S000399E)
Authentication type used when local users have individual access rights.
Authentication type used when access rights comes from a central server for user
User Name – Enter the user's name in lowercase.
Password – Enter the user's password (in lowercase).
Confirm Password – Retype the password to confirm it.
Static IP Address – Enter the specific Static IP Address from the range so that the
server will issue it to the client when it is connected.
Allowed Users – The names of the users entered above display in this text box. If you
wish to delete a name, click the Delete button.
Prerequisite Step – In order to select RADIUS as the authentication type, you must set
up a PPTP network by going to the Network & Services > Network Configuration
screen and enter a Network Name, IP Address and Subnet Mask as in this example:
Return to the VPN > PPTP Screen –
Authentication Type –
RADIUS Server Address –
RADIUS Server Secret –
Chapter 5 – Configuration Using Web Management Software
Select PPTP-POOL as the Remote Address:
Select RADIUS.
Enter the RADIUS server IP Address.
Enter the secret which is configured in the RADIUS server.
VPN > PPTP
