- Page 1 ® RouteFinder SOHO Internet Security Appliance RF820 / RF830 / RF825 Port Forwarding Setup Reference Guide...
- Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes. Revision...
-
Page 3: Port Forwarding
Note: Pictured below is an RF820 screen with the single WAN ports. The RF830 screen is the same except for the addition of WAN2 and WAN2Interface. private1 The new network name displays at the bottom of the screen. Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide 192.168.2.20 255.255.255.255 Port Forwarding... - Page 4 DNAT server. Example: Service Name: RDP Protocol: TCP+UDP S-Port/Client: 1:65535 D-Port/Server: 3389 Click the Add button. The new port displays at the bottom of the screen: Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide Port Forwarding...
- Page 5 The new DNAT rule displays at the bottom of the screen. Repeat Step 2 for other ports you want to map. Click the Add button after each rule. Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide private1 Port Forwarding...
- Page 6 Restart This is optional. You do not have to restart the RouteFinder after saving to the flash memory. Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide Port Forwarding Note: Do not check the Status...
- Page 7 Create a name for public IP Address: Name: public1 IP Address: 40.22.1.1 Subnet Mask: 255.255.255.255 Click the Add button. public1 Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide 40.22.1.1 255.255.255.255 The new network name displays at the bottom of the screen. Port Forwarding...
- Page 8 Name: private1 IP Address: 192.168.2.20 Subnet Mask: 255.255.255.255 Click the Add button. public1 private1 Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide 40.22.1.1 255.255.255.255 192.168.2.20 255.255.255.255 The new network names display at the bottom of the screen.
- Page 9 Restart This is optional. You do not have to restart the RouteFinder after saving to the flash memory. Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide SMTP private1 SMTP...
-
Page 10: Appendix - A Reference Table Of Commonly Supported Subnets
N.N.N.120 N.N.N.128 N.N.N.136 N.N.N.144 N.N.N.152 N.N.N.160 N.N.N.168 N.N.N.176 N.N.N.184 Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide Appendix – A Reference Table of Commonly Supported Subnets Hosts Available Broadcast Address N.N.N.1-126 N.N.N.127 N.N.N.129-254 N.N.N.255 Hosts Available Broadcast Address N.N.N.1-62... - Page 11 N.N.N.212 N.N.N.216 N.N.N.220 N.N.N.224 N.N.N.228 N.N.N.232 N.N.N.236 N.N.N.240 N.N.N.244 N.N.N.248 N.N.N.252 Multi-Tech Systems, Inc. RF820/RF830/RF825 Port Forwarding Setup – A Reference Guide Appendix – A Reference Table of Commonly Supported Subnets N.N.N.193-198 N.N.N.199 N.N.N.201-206 N.N.N.207 N.N.N.209-214 N.N.N.215 N.N.N.217-222 N.N.N.223 N.N.N.225-230 N.N.N.231...
