Summary of Contents for Multitech Conduit MTCDT Series

  • Page 1 ® Conduit Hardware Guide...
  • Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
  • Page 3: Table Of Contents

    CONTENTS Contents Chapter 1 – Product Overview ..........................5 Introduction .................................. 5 Product Kit Contents ..............................6 Build Options................................. 7 Chapter 2 – Specifications............................9 Conduit Specifications..............................9 Dimensions.................................. 11 Backpanel Connectors..............................12 LED Descriptions ................................. 13 Chapter 3 – Power Draw ............................15 MTCDT-H5-246 with Modem and No Accessory Cards Power Draw .................
  • Page 4 CONTENTS Chapter 6 – Regulatory Information........................34 Conduit Regulatory Information ..........................34 ® Conduit Hardware Guide...
  • Page 5: Chapter 1 - Product Overview

    PRODUCT OVERVIEW Chapter 1 – Product Overview Introduction ® Conduit is a programmable gateway that uses an open Linux development environment to enable machine-to- machine (M2M) connectivity using various wireless interfaces. It also provides an online application store for industrial things as a platform for developers to provision and manage their gateway and associated sensors and devices.
  • Page 6: Product Kit Contents

    PRODUCT OVERVIEW Product Kit Contents Your Product Kit includes the following (varies with model): Device 1 - MTCDT-Conduit Power Supply 1 - 100-240V 9V-1.7A power supply with removable blades 1 - NAM blade/plug 1 - EURO blade/plug 1 - UK blade/plug Cables 1 - Micro USB Cable 1 - Ethernet Cable RJ45 6-ft.
  • Page 7: Build Options

    PRODUCT OVERVIEW Build Options Product Description Region MTCDT-246L-US-EU-GB mLinux Programmable Gateway using GNSS Global w/US/EU/UK Accessory Kit MTCDT-246A-US-EU-GB mPower Gateway using GNSS w/US/EU/UK Accessory Global MTCDT-246A-915-US-EU-GB mPower Programmable Gateway 8-channel, 915 MHz, using MTAC-LORA-H-915 mCard, GNSS, and US/EU/UK Accessory Kit MTCDT-246A-868-EU-GB mPower Programmable Gateway 8-channel, 868 MHz, EU/UK...
  • Page 8 PRODUCT OVERVIEW Product Description Region MTCDT-247A-US-EU-GB mPower Programmable Gateway using GNSS and Global WiFi/BT w/US/EU/UK Accessory Kit MTCDT-H5-247L-US-EU-GB HSPA+ mLinux Programmable Gateway using GNSS and Global WiFi/BT w/US/EU/UK Acc Kit MTCDT-H5-247A-US-EU-GB HSPA+ mPower Programmable Gateway using GNSS Global and WiFi/BT w/US/EU/UK Acc Kit MTCDT-LEU1-247L-US-EU-GB Conduit LTE mLinux Programmable Gateway using Global...
  • Page 9: Chapter 2 - Specifications

    SPECIFICATIONS Chapter 2 – Specifications Conduit Specifications Category Description Physical Description Dimensions See the Conduit Demensions Drawing Weight 15.6 oz. (442.25 grams) with no accessory cards installed Connectors Connectors 1 USB device micro Type B debug port (behind nameplate) 1 RJ-45 Ethernet port 1 USB micro port 2 cellular antenna connectors 1 Wi-Fi/Bluetooth connector...
  • Page 10 SPECIFICATIONS Optional power must be UL Listed ITE power supply marked LPS or Class 2 rated 12 VDC, 5A. Certification does not apply or extend to Voltages outside certified range, and has not been evaluated by UL for operating voltages beyond tested range.
  • Page 11: Dimensions

    SPECIFICATIONS Dimensions ® Conduit Hardware Guide...
  • Page 12: Backpanel Connectors

    AUX - Diversity. AP1, AP2 Slots for MultiTech accessory cards. You can install an accessory card in either slot. Both slots can be occupied at one time. An exception is an SDIO (Secure Digital Input/Output) card, which can be used only in the AP1 slot.
  • Page 13: Led Descriptions

    SPECIFICATIONS LED Descriptions Conduit mLinux Model Front Panel Conduit mPower Model Front Panel Label Name Description Power Solid (constant) green if unit is on indicating that DC power is present. STATUS Power Status Default condition: LED blinks when mLinux is fully loaded. Link Status Varies with radio model.
  • Page 14 SPECIFICATIONS Label Name Description Signal Signal Strength These 3 LEDs display the strength of the cellular signal. Present on the Conduit mPower model only. If a cellular radio is installed, the typical LS (Link Status) LED behavior is the following: OFF - No power to the cellular radio Continuously Lit - Not registered Slow Blink (-0.2Hz) - Registered or connected...
  • Page 15: Chapter 3 - Power Draw

    POWER DRAW Chapter 3 – Power Draw MTCDT-H5-246 with Modem and No Accessory Cards Power Draw Radio Protocol Idle Cellular Average Tx Peak Tx Current Total Inrush Total Inrush Connection no Current at Max (Amps) Charge (mC) Charge Duration data (Amps) Power passing (mS) data (Amps)
  • Page 16: Mtcdt-Lvw2-246 With Modem And No Accessory Cards

    POWER DRAW Radio Protocol Idle Cellular Average Tx Peak Tx Current Total Inrush Total Inrush Connection no Current at Max (Amps) Charge (mC) Charge Duration data (Amps) Power Passing (mS) Data (Amps) 0.102 0.249 0.316 3.65 17.9 Max Power: The continuous current during maximum data rate with the radio transmitter at maximum power. Peak Tx Current: The average peak current during an EGSM900 transmission burst period or LTE connection.
  • Page 17 POWER DRAW Voltage No Connections Ethernet Maximum Total Inrush Total Inrush (Amps) Connected only Current (Amps) Charge (mC) Charge Duration (Amps) (mS) 24.0 Volts 0.081 0.086 0.114 2.48 14.6 No Connections: Typical measure performed with the unit powered up only–no connections to the device. Ethernet Connected Only: Typical power with Ethernet measured and the device attached to PC with Ethernet cable only.
  • Page 18: Mtcdt-210 With Modem And No Accessory Cards Power Draw

    POWER DRAW MTCDT-210 with Modem and no Accessory Cards Power Draw Radio Protocol Idle Cellular Average Tx Peak Tx Current Total Inrush Total Inrush Connectionno Current at Max (Amps) Charge (mC) Charge Duration data (Amps) Power passing (mS) data (Amps) 9.0 Volts GSM 850 MHz 0.200...
  • Page 19: Mtcdt- Lat1-210 With Modem And No Accessory Cards

    POWER DRAW Peak Tx Current: The average peak current during an EGSM 900 transmission burst period or LTE connection. The transmission burst duration for EGSM 900 can very, depending on what transmission scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.). Total Inrush Charge: The total inrush charge at power on expressed in Millicoulombs (mC).
  • Page 20: Mtcdt-210 No Modem And No Accessory Cards

    POWER DRAW Radio Protocol Idle Cellular Average Tx Peak Tx Current Total Inrush Total Inrush Connection no Current at Max (Amps) Charge (mC) Charge Duration data (Amps) Power Passing (mS) Data (Amps) 24.0 Volts 0.096 0.227 0.300 2.75 7.43 Max Power: The continuous current during maximum data rate with the radio transmitter at maximum power. Peak Tx Current: The average peak current during LTE connection.
  • Page 21: Mtcdt-Leu1-247 With Bluetooth, Wi-Fi, And No Accessory Cards Power Draw

    POWER DRAW MTCDT-LEU1-247 with Bluetooth, Wi-Fi, and No Accessory Cards Power Draw Radio Protocol Idle Cellular Call Average TX Pulse (AVG) Total Inrush Total Inrush Box Connection Measured Amplitude Charge Charge Duration No Data Current at Max Current for Measured During Powerup Power (Wi-Fi GSM850 or Peak...
  • Page 22: Chapter 4 - Frequency Information

    FREQUENCY INFORMATION Chapter 4 – Frequency Information Frequency Bands for Conduit Cellular Radio Frequencies LE910-Eug 2G 900/1800, 3G 850/900/2100, LTE/FDD 800/1800/2600 LEU1 LE910-NAG 2G 850/1900, WCDMA 850/1900, LTE/FDD 700/850, AWS 1700/1900 LAT1 LE910-SVG LVW2 AWS 1700 HE910-D GSM 850/900, DCS 1800, PCS 1900, WCDMA 800/850/900, AWS 1700/1900/2100 Frequency and Power Information for WiFi/Bluetooth Operating Frequency...
  • Page 23: Le910 Telit Transmission Output Power

    FREQUENCY INFORMATION Band Power Class EDGE, 850/900 MHz E2 (0.5W) EDGE, 1800/1900 MHz Class E2 (0.4W) WCDMA 850/900, AWS 1700, 1900/2100 MHz Class 3 (0.25W) LE910 Telit Transmission Output Power Band Power Class GSM 850/900 4 (2W) DCS 1800/PCS 1900 1 (1W) EDGE, 850/900 MHz E2 (0.5W)
  • Page 24: Chapter 5 - Setting Up And Configuring The Device

    Gently push the new SIM card into SIM card holder face up with the cut corner to the right and the SIM contacts facing toward the Conduit’s interior. If not installing a battery or micro SD card, reattach the MultiTech nameplate to the Conduit using the screw removed in Step 2.
  • Page 25: Accessory Port (Mcard) Interfaces

    SETTING UP AND CONFIGURING THE DEVICE Accessory Port (mCard) Interfaces The accessory card interface on the Conduit base board has the following interface options: Interface Description Used by all accessory cards. I2C is required for Electronic Identification (EID) support on the accessory card but can be used for other I2C devices.
  • Page 26: Installing A Micro Sd Card

    If replacing a battery, non-metal tweezers or similar object CR1632 standard coin lithium battery To install or replace the battery: If connected, disconnect power to the Conduit. At the front of the Conduit housing, remove the screw that secures the MultiTech nameplate to the housing. ® Conduit...
  • Page 27: Connecting To The Debug Interface

    Standard USB Micro B cable Disconnect power to the Conduit, if it is connected. At the front of the Conduit housing, remove the screw that secures the MultiTech nameplate to the housing. Locate and identify the USB debug cable connector in the center of the opening. Make sure have the appropriate cable available (if you have the 3-pin connector, see cable details below).
  • Page 28 SETTING UP AND CONFIGURING THE DEVICE If you have the 3-pin connector, connect the 3-pin cable to the debug connector. Connect the Type A end of the USB cable to the host. From the host, use an application such as TeraTerm with a baud rate of 115,200. If the USB driver does not automatically install, do the following: Unplug the USB cable.
  • Page 29 SETTING UP AND CONFIGURING THE DEVICE Purchase a USB to 3.3V Serial UART cable with a USB-A connector for the host end and three leads on the device end. See cable information for details. Purchase a 3-pin connector using crimp-style contacts for the device end of the cable. See connector information for details.
  • Page 30 SETTING UP AND CONFIGURING THE DEVICE Olimex cable FTDI Cable ® Conduit Hardware Guide...
  • Page 31: Restoring User Defined Settings

    SETTING UP AND CONFIGURING THE DEVICE Connector Information Description Manufacturer P/N or Product Number Contacts 3-pin connector with JST-ZHR-3 SZH-002T-P0.5 crimp-style contacts (female socket) Restoring User Defined Settings You need: A pin, paperclip, or similar thin object that can fit into the reset hole. To restore user defined settings for an mPower device: Locate the hole in the panel labeled RESET.
  • Page 32 SETTING UP AND CONFIGURING THE DEVICE For mLinux models: Press and hold the RESET button for less than 5 seconds, then release. Holding it beyond 5 seconds resets an mLinux device to factory defaults. The status LED will keep blinking normally for a couple of seconds until the unit resets. Then the status light will stay solid while the device reboots.
  • Page 33: Powering Up The Device

    Use only the power cord provided with the device. Using any other power cord voids the warranty and can damage the device. To power up the device: Install the desired MultiTech accessory card or cards into the slots at the back of the device. Refer to the appropriate installation documentation for the accessory card. Note: Some models already have MTAC cards installed.
  • Page 34 REGULATORY INFORMATION Chapter 6 – Regulatory Information Conduit Regulatory Information For regulatory infomration please see http://www.multitech.net/developer/products/multiconnect-conduit- platform/conduit/conduit-regulatory-information/ ® Conduit Hardware Guide...
