Heavy Duty Under Desk Gaming PC Mount
Instruction Manual
SKU: MOUNT-PC06E
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
MOUNT-PC06E_REV1.1 1
MOUNT-PC06E_REV1.1 1
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pc06e
www.vivo-us.com
Chat live with an agent!
309-278-5303
8/4/2023 4:01:09 PM
8/4/2023 4:01:09 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOUNT-PC06E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo MOUNT-PC06E

  • Page 1 Heavy Duty Under Desk Gaming PC Mount Instruction Manual SKU: MOUNT-PC06E Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pc06e GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3 ASSEMBLY STEPS STEP 1 Apply Pads (S-A) to top, bottom, and side of Mount (A) as shown. MOUNT-PC06E_REV1.1 3 MOUNT-PC06E_REV1.1 3 8/4/2023 4:01:10 PM 8/4/2023 4:01:10 PM...
  • Page 4 STEP 2 Hold the Mounting Template (T-A) up to the desired location on the underside of the desk and mark the hole locations with a pencil. Use a 5/32” (4mm) drill bit to drill the holes 1/2” (12mm) deep. MOUNT-PC06E_REV1.1 4 MOUNT-PC06E_REV1.1 4 8/4/2023 4:01:10 PM 8/4/2023 4:01:10 PM...
  • Page 5 STEP 3 Assemble Mount (A) to the desktop using ST4.8x16mm Screws (M-A), M5 Washers (M-B) and a Phillips screwdriver. MOUNT-PC06E_REV1.1 5 MOUNT-PC06E_REV1.1 5 8/4/2023 4:01:10 PM 8/4/2023 4:01:10 PM...
  • Page 6 STEP 4 Loosen the knob underneath Mount (A) to adjust the width, and flip the lever on the side up to adjust the height. Insert the PC. Underside of Mount MOUNT-PC06E_REV1.1 6 MOUNT-PC06E_REV1.1 6 8/4/2023 4:01:10 PM 8/4/2023 4:01:10 PM...
  • Page 7 STEP 5 Once the PC is in place, tighten knob underneath Mount (A) and flip the lever on the side down to lock it into place. Underside of Mount MOUNT-PC06E_REV1.1 7 MOUNT-PC06E_REV1.1 7 8/4/2023 4:01:11 PM 8/4/2023 4:01:11 PM...
  • Page 8 - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com MOUNT-PC06E_REV1.1 8 MOUNT-PC06E_REV1.1 8 8/4/2023 4:01:11 PM 8/4/2023 4:01:11 PM...
