Large Under Desk PC Mount
Instruction Manual
SKU: MOUNT-PC06L
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pc06l
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo MOUNT-PC06L
Summary of Contents for Vivo MOUNT-PC06L
- Page 1 Large Under Desk PC Mount Instruction Manual SKU: MOUNT-PC06L Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pc06l GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 STEP 2 Remove the Support Bar (B1) from Brace (B) using the 3mm Allen Wrench (T-A). Install the Support Bar (B1) and Brace (B) onto Mount (A) using the previously removed hardware and 3mm Allen Wrench (T-A). STEP 3 Adjust assembled mount as needed to fit your PC. This will help gauge the space consumed by the mount when determining your desired mounting location.
- Page 4 INSTALLATION STEPS INSTALLATION OPTIONS: Choose your desired installation method and follow appropriate steps below. Desk Mount Wood Wall Mount Brick/Cement Wall Mount Page 4 Page 5 Page 6 Desk Mount STEP 1 Hold Mount (A) up to desired mounting location and mark hole locations using a pencil. When marking the keyhole locations, ensure to only mark the narrow section of the keyhole.
- Page 5 STEP 3 Hang Mount (A) over screws, making sure they are in the larger part of the keyhole openings. Slide the mount toward the narrow keyhole opening to lock into place. The screw heads should now be holding up the unit. Tighten the screws fully and install the remaining two ST4.8x16mm Screws (W-A) using a Phillips screwdriver.
- Page 6 STEP 3 Hang Mount (A) over screws, making sure they are in the larger part of the keyhole openings. Slide the mount toward the narrow keyhole opening to lock into place. The screw heads should now be holding up the unit. Tighten the screws and install the remaining two ST4.8x38mm Screws (W-B) using a Phillips screwdriver.
- Page 7 STEP 3 Hang Mount (A) over screws, making sure they are in the larger part of the keyhole openings. Slide the mount toward the narrow keyhole opening to lock into place. The screw heads should now be holding up the unit. Tighten the screws and install the remaining two ST4.8x38mm Screws (W-B) using a Phillips screwdriver.
