Mask Lights Not Functioning Correctly; Pitlight Not Functioning Correctly - QubicaAMF Edge String Owner's Manual

Cause 2: System controller Foul Detector setting not set correctly
Solution: Set system controller Foul Detector setting to ON to allow foul

4.5.12. Mask Lights Not Functioning Correctly

Cause 1: Mask light unit malfunction
Solution: Check all electrical connections between mask light unit and
Cause 2: System controller Mask Lights setting not set correctly
Solution: Set system controller Mask Lights parameter to AS BALL

4.5.13. Pitlight Not Functioning Correctly

Cause 1: Pitlight/system controller malfunction
Solution: Restart power to system controller. Check all electrical
Cause 2: System controller Pit Light setting not set correctly
Solution: Set system controller Pit Light setting to WHITE for white light
400-051-202-01 Rev. B
25). Restart power to system controller. Replace components
as needed.
detector activation to control scoring. Set to WARNING for
warning only (no effect on scoring). Set to OFF to deactivate
foul detector (see Page 2-21).
system controller. In the Text sub-menu of the system controller
Diagnostics menu, verify that Mask Light On status alternates
between BALL 1 and BALL 1/BALL 2 for each frame (see
Page 2-24). Restart power to system controller. Replace
components as needed.
NUMBER (see Page 2-21).
connections between system controller and pit light (including
ground wire). If operating with CenterPunch Effects Server,
check electrical connections to adjacent system controllers and
refer to manual 400-275-000 for proper effects server
installation/operation.
only. Set to COLOR for alternative light color.
Owner's Manual
Page 4-16
