Section Overview

This section provides an overview of the EDGE String, including descriptions of the
major components/sub-assemblies, user-configurable settings, diagnostics tools, and
machine operation. It also explains how to use the system controller keypad/display, the
primary user interface for machine operation and routine maintenance tasks.
Applicable Safety Warnings
Major Components & Subassemblies
Figure 2-1 shows the EDGE String installed in a pinspotter pair configuration. Both pair and single pinspotter
configurations are available. The following section outlines the major machine components/subassemblies with
brief descriptions of each item.

2.2.1. Pinspotter Pair

400-051-202-01 Rev. B
Figure 2-1, EDGE String Pinspotter Pair
Owner's Manual
Page 2-3
