Cause 3: Foreign object on playing surface.
Solution: Clean pindeck (see Page 3-4).

4.5.9. System Controller Keypad Non-Responsive

Cause 1: Faulty keypad/system controller
Solution: Using the Keypad Test tool in the system controller Diagnostics

4.5.10. Machine Not Scoring Correctly

Cause 1: System controller Scoring System setting not set correctly
Solution: If operating with QubicaAMF scoring, set system controller
Cause 2: System controller Game setting not set correctly.
Solution: Set system controller Game setting to 10 PINS (see Page 2-21).
Cause 3: System controller Inhibit Pin Errors setting not set correctly
Solution: Set system controller Inhibit Pin Errors setting to OFF see
Cause 4: System controller Pin Data Delay setting not set correctly
Solution: Factory default setting is 3.0 seconds. (see Page 2-21).
Cause 5: System controller Pin Detect Count setting not set correctly
Solution: Recommended setting is 12 (see Page 2-21). Increasing value

4.5.11. Foul Detector Not Functioning Correctly

Cause 1: Foul detector malfunction
Solution: Check foul detector/reflector alignment. Check for any damage
400-051-202-01 Rev. B
menu (see Page 2-25) test any non-functioning pushbuttons.
Restart power to system controller. Replace system controller if
needed.
Scoring System setting to SCORING. If operating with non-
QubicaAMF scoring, set to BASIC or STANDALONE. See
Page 2-21.
Page 2-22). System controller will now output pin encoder and
pin brake errors (if applicable), which can then be addressed.
Increasing value will provide more time for pin action to settle
before frame is scored but will delay start of next machine
cycle.
will allow for greater pin shift (off-spotting) during play but
may not score a pin correctly if value is set too high.
or dust on reflector and sensor. Check all electrical connections
between foul detector and system controller. In the Text sub-
menu of the system controller Diagnostics menu, verify that
Foul Detector status alternates between FOUL and NO FOUL
while passing object through detector beam (see Page 2-24, 2-
