QubicaAMF Edge String Owner's Manual page 202

Precautions: LOTO, Lane Barriers, Slip Hazard
Tools:
• Ratchet or Impact Driver
• ½" Socket
• ½" Wrench
Location: Operator Access Area (behind machine), Pit
Est. Time: 20 min
Note:
• The estimated time assumes an impact driver is used.
Procedure:
1. Implement LOTO and deploy lane barriers.
2. Remove pit rear guards (both pits) and double division guard.
3. Unclip bowtie cotter pin from bottom of shock and remove pin attaching shock to
cushion. Set hardware aside.
4. Remove bolt and nut retaining opposite ball door side cushion block.
5. Slide cushion block and cushion forward.
6. Set aside cushion block and shield plate.
7. Rotate cushion to pull out of other cushion block.
8. Remove cushion assembly from pit.
9. Follow above steps in reverse order to install cushion assembly. Ensure shield plate is
installed in each cushion block.
10. Remove LOTO and lane barriers. Return machine to service.
