DETANGLING
DISABLED
DRAWBAR 1
DRAWBAR 2
DRIVE ERR 1
DRIVE ERR 2
DRIVE ERR 3
400-051-202-01 Rev. B
Machine is performing a detangle routine. Code will clear
automatically once all pin strings are detangled or once detangle
routine times out. A detangling routine can be stopped by pressing
WORK.
System controller could not initialize all system components
during start-up. Restart power to system controller. Check all
electrical connections between system controller and control box.
Replace electrical cable(s) if needed. Replace system controller
and/or control box if needed. Note, code will always be displayed
for missing lane of a single lane installation.
Drawbar movement is restricted. Press WORK then PLAY to
clear error. Restart power to machine control box, press FULL
SET, then press PLAY. Check that drawbar drive system is not
jammed (drive chains too tight, internal string tangle, worn
components, etc.). Check all electrical connections between
control box and motor. Replace motor control box and/or motor if
needed. Check coupling hubs for loose setscrews and key/keyway
wear.
Expected drawbar motor encoder count was not reached within the
pre-programmed time. Press WORK then PLAY to clear error.
Restart power to machine control box, press FULL SET, then
press PLAY. Check that drawbar drive system is not jammed
(drive chains too tight, internal string tangle, worn components,
etc.). Check all electrical connections between control box and
motor. Replace control box and/or motor if needed.
Machine control box does not recognize drawbar motor. Press
WORK then PLAY to clear error. Restart power to control box,
press FULL SET, then press PLAY. Check all electrical
connections between control box and motor. Replace control box
and/or motor if needed.
Machine control box over-voltage condition. Press WORK then
PLAY to clear error. Restart power to control box, press FULL
SET, then press PLAY. Check all electrical connections between
control box and drawbar motor. Replace control box and/or motor
if needed.
Machine control box over-temperature condition. Press WORK
then PLAY to clear error. Restart power to control box, press
FULL SET, then press PLAY. Check that drawbar drive system
is not jammed (drive chains too tight, internal string tangle, worn
components, etc.). Check all electrical connections between
control box and motor. Replace control box and/or motor if
needed.
