Precautions: LOTO and Lane Barriers, Slip Hazard
Tools:
• Ratchet or Impact Driver
• ½" Socket
• ½" Wrench
Location: Operator Access Area (behind machine), Pit
Est. Time: 10 min
Note:
• The estimated time assumes an impact driver is used.
Procedure:
1. Implement LOTO and deploy lane barriers.
2. Remove pit rear guard.
3. Unclip bowtie cotter pin from bottom of cushion shock. Remove pin and flat washer and
set aside.
4. Remove bolt and nut retaining each cushion block.
5. Slide cushion blocks and cushion forward. Set cushion assembly on pit floor.
6. Replace cushion block and reinstall following above steps in reverse order. Ensure shield
plate is installed in each cushion block.
7. Remove LOTO and lane barriers. Return machine to service.
Precautions: LOTO, Lane Barriers, Slip Hazard
Tools:
• Ratchet or Impact Driver
• ½" Socket
Location: Operator Access Area (behind machine), Pit
Est. Time: 5 min
Note:
• The estimated time assumes an impact driver is used.
Procedure:
1. Implement LOTO and deploy lane barriers.
2. Remove pit rear guards (both pits) and double division guard.
3. Unclip bowtie cotter pins from cushion shock.
4. Remove pins and flat washers at top and bottom of shock and set aside.
5. Follow above steps in reverse order to install cushion shock.
6. Remove LOTO and lane barriers. Return machine to service.
