DPS Telecom TempDefender G2 User Manual page 16

10
LED
A
B (Optional)
FA
Status
Alarm
Serial
Power
(Lamp)
USB
D-Wire
Lnk
LAN
100BT
Analog
Relay
Status
Solid Green Power Supply A OK
Off No Voltage (or) Power Leads Reversed
Solid Green Power Supply B OK
Off No Voltage (or) Power Leads Reversed
Solid Red Blown Fuse
Off Fuse OK
Flashing Green Application Running
Flashing Red Bootloader Running
Flashing Red New Alarm
Solid Red Standing Alarm Acknowledged via DCP poll
Off No Alarms
Flashing Green Data Transmitted on Serial Connection
Flashing Red Data Received on Serial Connection
Solid Green Processor has power
Off Processor does not have power
Flashing Green Data Transmitted over USB
Flashing Red Data Received over USB
Solid Green At least 1 dwire enabled, no alarm
Flashing Green Standing acknowledged alarm (Threshold)
Flashing Red New Alarm
Off No D-Wire Alarms
Solid Green LAN Connected
Off LAN Not Connected
Flashing Yellow Activity over Ethernet Connection
Off No Activity
Solid Green LAN Connection Speed is 100BaseT
Off LAN Connection Speed is 10BaseT
Solid Green Analogs enabled, no alarm
Solid Red Standing acknowledged alarm (Threshold)
Flashing Red New Alarm
Off No Analogs enabled
Solid Green 1 or more relays latched
Flashing Green New relay latched or released
Off All relay off
Front Panel LED Descriptions
Description
